M9R81463 - Residual current circuit breaker (RCCB), Multi9 GFP, 4P, 63A, A-SI type, 30mA - Schneider Electric
| Cat No. | M9R81463 |
| Category | MCB Accessories |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB Accessories |
Back Ordered
$532.36
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 30 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider M9R81463 MCB Accessories Technical Specification
| MCB Accessories | |
|---|---|
| Other Details | 63A |
| Range of Product | Multi9 |
| Sub Family | GFP |
| Sub Family | GFP |
| Type | Acti9 |
Product Details
Schneider Electric M9R81463 - This product is a Multi GFP residual current circuit breaker (RCCB). It is a 4P circuit breaker with 63A In rated current, a sensitivity of 26mA with a A-SI type protection class. It protects persons against electric shock by direct contact. It also protects installations against fire risks. The tripping upon fault is indicated by a red mechanical status indicator on the front panel. The A-SI type offers enhanced immunity to electrical disturbances. This product is dedicated to original equipment manufacturers (OEM) and control panel builders in indisutrial and tertiary buildings. It is compliant with IEC/EN 61008-1 standard. The (Im/IΔm) rated breaking and making short circuit capacity is 1500A. The (Inc/IΔc) conditional rated short circuit current is 10kA. It has a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 240VAC. The Ui rated insulation voltage is 440VAC. The Uimp rated impulse withstand voltage is 6kV. The frequency is 50Hz or 60Hz. It is DIN rail mountable. The width in 9mm pitches is 8. The product colour is light grey (RAL7035). The dimensions are (W) 72mm x (H) 81mm x (D) 60mm. The weight is 0.45kg. It has an IP20 degree of protection (as per IEC/EN 60529 standard) and becomes IP40 once in modular enclosure. The operating temperature is from -25°C to 60°C. The storage temperature is from -40°C to 70°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider M9R81463 dimensions and weight
Weight
Net Weight
0.375 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
