A9N26899 - Acti 9 - low level auxiliary contact OF+SD - for C60, C120, C60H-DC, DPN, ID - Schneider Electric
| Cat No. | A9N26899 |
| Category | MCB Accessories |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB Accessories |
In Stock — 31 Qty
$54.27
| Quantity | Expected Delivery |
|---|---|
| 31 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 32 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9N26899 MCB Accessories Technical Specification
| MCB Accessories | |
|---|---|
| Other Details | OF+SD24 |
| Range of Product | — |
| Sub Family | Aux. Contact |
| Sub Family | — |
| Type | Acti9 |
Product Details
Schneider Electric A9N26899 - This Acti9 OF+SD24 electrical auxiliary is a double open/close or fault indicator contact,It is dedicated to iD, C60, C120, DPN, DPN Vigi, C60H-DC, SW60-DC, C60PV-DC, C60NA-DC, C120NA-DC,It reports also the electrical fault, actuation of the tripping auxiliary, open or closed position of the associated device informations to a programmable logic controller,Remote indication of position and tripping upon a fault of the associated device,The 2 contacts (1NO + 1NC) can report the signalling information of the associated device to the Acti9 Smartlink,The width in 9mm pitches is 1,It is a ComReady device. There is a Test function on the toggle,The Ue rated operational voltage is 24VDC,The In rated operational current is 2mA (mini) up to 100 mA (maxi),The operating temperature is -25°C to + 70°C. The storage temperature is -40°C to + 85°C,This product complies with IEC/EN 60947-5-1. and IEC/EN 60947-5-4 standards. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9N26899 dimensions and weight
Dimensions (L × W × H)
Length
9.5 cm
Width
2 cm
Height
8 cm
Weight
Net Weight
0.036 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
