A9N26948 - MX Shunt Trip MX plus 1 OF 24Vac dc - Schneider Electric
| Cat No. | A9N26948 |
| Category | MCB Accessories |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB Accessories |
In Stock — 155 Qty
$55.62
| Quantity | Expected Delivery |
|---|---|
| 155 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 20 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9N26948 MCB Accessories Technical Specification
| MCB Accessories | |
|---|---|
| Other Details | MX + OF |
| Range of Product | — |
| Sub Family | Shunt Release |
| Sub Family | — |
| Type | Acti9 |
Product Details
Schneider Electric A9N26948 - This Acti9 MX+OF shunt trip release is an electric tripping auxiliary with open/close auxiliary contact,It is dedicated to C60, C120, DPN, DPN Vigi, C60H-DC, SW60-DC, C60PV-DC, C60NA-DC, C120NA,This device includes an open/close contact OF to indicate the position of the circuit breaker,Emergency stoppage by normally open pushbutton. It provides a remote indication of the position of the associated device,The product trips the associated device when it is powered on,The width in 9mm pitches is 2,There is a mechanical state indicator light, red on the front face,The Ue rated operational voltage is 24 to 24VDC or 12 to 24VAC. The operating frequency is 50Hz or 60Hz,The Ie rated operational current is 6A under 24VDC, 2A under 48VDC, 1.5A under 60VDC, 1A under 130VDC,The Ie rated operational current is 6A under 24VAC to 240VAC, 3A under 415VAC,The operating temperature is -25°C to + 50°C. The storage temperature is -40°C to + 85°C,This product complies with IEC/EN 60947-5-1 standards. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9N26948 dimensions and weight
Dimensions (L × W × H)
Length
9.4 cm
Width
3 cm
Height
7.8 cm
Weight
Net Weight
0.074 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric A9N26948 - This Acti9 MX+OF shunt trip release is an electric tripping auxiliary with open/close auxiliary contact,It is dedicated to C60, C120, DPN, DPN Vigi, C60H-DC, SW60-DC, C60PV-DC, C60NA-DC, C120NA,This device includes an open/close contact OF to indicate the position of the circuit breaker,Emergency stoppage by normally open pushbutton. It provides a remote indication of the position of the associated device,The product trips the associated device when it is powered on,The width in 9mm pitches is 2,There is a mechanical state indicator light, red on the front face,The Ue rated operational voltage is 24 to 24VDC or 12 to 24VAC. The operating frequency is 50Hz or 60Hz,The Ie rated operational current is 6A under 24VDC, 2A under 48VDC, 1.5A under 60VDC, 1A under 130VDC,The Ie rated operational current is 6A under 24VAC to 240VAC, 3A under 415VAC,The operating temperature is -25°C to + 50°C. The storage temperature is -40°C to + 85°C,This product complies with IEC/EN 60947-5-1 standards. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for A9N26948
Every Schneider A9N26948 MCB Accessories purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCB Accessories for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCB Accessories for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The Schneider A9N26948 is designed to be compatible with specific MCB ranges such as Acti9 iC60 or xC60. It is essential to verify the series compatibility to ensure the mechanical link and electrical connections align perfectly.
The A9N26948 accessory typically serves as either an auxiliary contact (for status signaling), a trip unit (like shunt trip or undervoltage trip), or a lockout device. It enhances the automation and safety capabilities of your electrical panel.
The A9N26948 accessory usually clips onto the left or right side of the MCB without the need for complex tools. Ensure the main breaker is powered off before attempting to snap the accessory into place and engaging the mechanical lever.
If the A9N26948 is a shunt trip or undervoltage release accessory, it can be integrated with emergency stop buttons or fire alarm systems to remotely trip the MCB, providing an added layer of safety for industrial setups in India.
The Schneider A9N26948 is built to withstand the tropical climate conditions of India, with high heat resistance and durable casing. It maintains operational integrity within the standard temperature ranges specified in the Schneider Electric catalog.
The A9N26948 is a versatile accessory designed for the Acti9, Multi9, or Resi9 ranges. This global compatibility ensures that engineers can standardize their signaling and tripping components across international projects.
The A9N26948 provides real-time feedback on the breaker's status (ON/OFF or Tripped). This is vital for industrial automation and remote diagnostics in large-scale global power distribution systems.
Depending on the specific part number, the A9N26948 can act as a Shunt Trip for remote emergency shutdown or an Undervoltage release to protect motors from brownouts, adhering to global industrial safety protocols.
The A9N26948 features a tool-free, snap-on mounting system. It aligns with the mechanical linkage of the breaker, ensuring reliable operation without compromising the dielectric strength of the assembly.
As a global product, the A9N26948 often carries multiple certifications including UL and CSA for the North American market, as well as CE marking for Europe, ensuring it meets strict international quality standards.
