A9N26929 - Acti 9 - Auxiliary contact OC plus 1 SD and OF ac dc - Schneider Electric
| Cat No. | A9N26929 |
| Category | MCB Accessories |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB Accessories |
In Stock — 27 Qty
$79.97
| Quantity | Expected Delivery |
|---|---|
| 27 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 44 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9N26929 MCB Accessories Technical Specification
| MCB Accessories | |
|---|---|
| Other Details | OF+ SD/OF |
| Range of Product | — |
| Sub Family | Aux Switch |
| Sub Family | — |
| Type | Acti9 |
Product Details
Schneider Electric A9N26929 - This Acti9 OF+SD/OF electric auxiliary is a double open/closed or fault indicator contact,It is dedicated to Acti9 C120, C60H-DC, DPN N Vigi,It comes with 1 changeover contact indicating the open or closed position (OF),It provides a remote position open/close and/or fault tripping indication of the associated device,It is a two-in-one product. The choice of OF+SD or OF+OF contact is made via the selector switch on front face,The width in 9mm pitches is 1,The Ue rated operational voltage is 24VAC to 415VAC or 24VDC to 130VDC. The operating frequency is 50Hz or 60Hz,The Ie rated operational current is 6A under 24VDC, 2A under 48VDC, 1.5A under 60VDC, 1A under 130VDC,The Ie rated operational current is 6A under 24VAC to 240VAC, 3A under 415VAC,There is a mechanical state indicator and a test function button on the front face,The operating temperature is -25°C to + 50°C. The storage temperature is -40°C to + 85°C,This product complies with IEC/EN 60947-5-1 standard and EN 62019-2 standard only for C120. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9N26929 dimensions and weight
Dimensions (L × W × H)
Length
9.2 cm
Width
8 cm
Height
2.2 cm
Weight
Net Weight
0.038 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric A9N26929 - This Acti9 OF+SD/OF electric auxiliary is a double open/closed or fault indicator contact,It is dedicated to Acti9 C120, C60H-DC, DPN N Vigi,It comes with 1 changeover contact indicating the open or closed position (OF),It provides a remote position open/close and/or fault tripping indication of the associated device,It is a two-in-one product. The choice of OF+SD or OF+OF contact is made via the selector switch on front face,The width in 9mm pitches is 1,The Ue rated operational voltage is 24VAC to 415VAC or 24VDC to 130VDC. The operating frequency is 50Hz or 60Hz,The Ie rated operational current is 6A under 24VDC, 2A under 48VDC, 1.5A under 60VDC, 1A under 130VDC,The Ie rated operational current is 6A under 24VAC to 240VAC, 3A under 415VAC,There is a mechanical state indicator and a test function button on the front face,The operating temperature is -25°C to + 50°C. The storage temperature is -40°C to + 85°C,This product complies with IEC/EN 60947-5-1 standard and EN 62019-2 standard only for C120. We are dedicatedly involved in providing an excellent quality products at Electrihub.
