A9XPC648 - comb busbar, Acti9, 1L+N, 9 mm pitch, 48 modules, 80 A - Schneider Electric
| Cat No. | A9XPC648 |
| Category | MCB Accessories |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB Accessories |
Back Ordered
$134.85
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 28 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9XPC648 MCB Accessories Technical Specification
| MCB Accessories | |
|---|---|
| Other Details | 1PN |
| Range of Product | Acti9 |
| Sub Family | Busbar |
| Sub Family | Busbar |
| Type | Acti9 |
Product Details
Schneider Electric A9XPC648 - Experience the efficient and safe power distribution with the Acti9 comb busbar, featuring a horizontal, insulated, cuttable design for customized installations. Dedicated to (Neutral, Line) installations, the comb busbar ensures a reliable distribution type (N, L1). It has a width of 48 modules of 18mm, ensuring compatibility with various installations. Suitable for 48 devices of 1P+N, the comb busbar features a distance of 18mm between ways, ensuring optimal compatibility and efficiency. It is compatible with Acti9 devices such as C40, Vigi iCG40, iID40, C40 Vigi, iDPN, iDPN Vigi, IDc, iC40, iCV40, Multi9 N40, and Multi9 N40 Vigi. Its current rating is 80A at 40°C, and the rated operational voltage is 230VAC between phase and neutral. The rated insulation voltage is 400VAC, and the rated impulse withstand voltage is 4kV. Additionally, the pollution degree 3 ensures reliable performance in challenging environments. Its colour is white (RAL 9003). The resistance to flames and abnormal heat is rated at 960°C within 30 seconds, in accordance with IEC 60695-2-1 standard, ensuring superior safety and durability. This comb busbar complies with EN/IEC 61439-1 standard. The Acti9 protection range provides security and simplicity with devices easy to install as well as to dismount. Composed of robust and stylish products, they answer all the needs for efficiency and reliability. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9XPC648 dimensions and weight
Weight
Net Weight
0.328 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
