A9GSB392 - Fuse Disconnector, Acti9 SBI, 3P, 125A, for fuse 22 x 58mm - Schneider Electric
| Cat No. | A9GSB392 |
| Category | MCB Accessories |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB Accessories |
Back Ordered
$191.53
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 43 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9GSB392 MCB Accessories Technical Specification
| MCB Accessories | |
|---|---|
| Other Details | 3P |
| Range of Product | Acti9 |
| Sub Family | Fuse |
| Sub Family | Fuse |
| Type | Acti9 |
Product Details
Schneider Electric A9GSB392 - This Acti9 SBI product is a fuse-disconnector. It brings safety, reliable solution for Buildings, Industry and OEMs with high breaking capacity. It is a 3 poles fuse-disconnector, up to 125A rated current (In), and gG or aM fuse curve with a fuse cartridge size of 22mm x 58mm. The general purpose of gG fuse is to provides overload and short-circuit protection. The aM fuse for motor application provides short-circuit protection (protection of loads with a high peak current). This product complies with IEC EN 60947-3 standard. The rated operational voltage (Ue) is up to 690VAC. The screw clamp terminals connection allows rigid copper cable (1 cable) and flexible copper cable (1 cable). The cable cross section capacity is from 2.5mm² to 25mm². This fuse-disconnector comes with padlocking. It can be mounted on DIN rail for modular installation. The width in 9mm pitches is 12. The dimensions are (W) 105mm x (H) 126.5mm x (D) 70mm. The pollution degree is 3. The tightening torque of connection is 3.5N.m for PZ2 screwdriver type. The operating temperature is from -20°C to +60°C. The storage temperature is from -40°C to +80°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9GSB392 dimensions and weight
Weight
Net Weight
0.555 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric A9GSB392 - This Acti9 SBI product is a fuse-disconnector. It brings safety, reliable solution for Buildings, Industry and OEMs with high breaking capacity. It is a 3 poles fuse-disconnector, up to 125A rated current (In), and gG or aM fuse curve with a fuse cartridge size of 22mm x 58mm. The general purpose of gG fuse is to provides overload and short-circuit protection. The aM fuse for motor application provides short-circuit protection (protection of loads with a high peak current). This product complies with IEC EN 60947-3 standard. The rated operational voltage (Ue) is up to 690VAC. The screw clamp terminals connection allows rigid copper cable (1 cable) and flexible copper cable (1 cable). The cable cross section capacity is from 2.5mm² to 25mm². This fuse-disconnector comes with padlocking. It can be mounted on DIN rail for modular installation. The width in 9mm pitches is 12. The dimensions are (W) 105mm x (H) 126.5mm x (D) 70mm. The pollution degree is 3. The tightening torque of connection is 3.5N.m for PZ2 screwdriver type. The operating temperature is from -20°C to +60°C. The storage temperature is from -40°C to +80°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
