A9D31716 - Acti 9 DPN N Vigi - RCBO - 3P+N - 16A - C Curve - 6000A - 30mA - type AC - Schneider Electric
| Cat No. | A9D31716 |
| Category | MCB Accessories |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB Accessories |
In Stock — 14 Qty
$223.26
| Quantity | Expected Delivery |
|---|---|
| 14 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 31 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9D31716 MCB Accessories Technical Specification
| MCB Accessories | |
|---|---|
| Other Details | 30mA |
| Range of Product | Acti9 |
| Sub Family | Vigi block |
| Sub Family | Vigi block |
| Type | Acti9 |
Product Details
Schneider Electric A9D31716 - This Acti9 DPN Vigi is a modular residual current breaker with overcurrent protection (RCBO). It is a 3P+N circuit breaker with 3 protected poles, In rated current of 16A and C tripping curve. The earth leakage protection class is AC type with a sensitivity of 30mA. The earth-leakage protection time delay is instantaneous. The Icn rated short circuit breaking capacity is up to 6000A according EN/IEC 61009-2-1 standard. This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards. Its earth fault indicator on front face allows quick identification of the type of default. It can be fitted instead og a miniature circuit breaker for complete protection of one circuit. This product is compliant with EN/IEC 61009-2-1 standard. It has an electrical endurance going up to 20000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is 380VAC to 415VAC. The Ui rated insulation voltage is 440VAC. The Uimp rated impulse withstand voltage is 4kV. The frequency is 50/60Hz. It is DIN rail mountable. The width in 9mm pitches is 10. The product color is white (RAL9003). The dimensions are (W) 90mm x (H) 91mm x (D) 78.5mm. The weight is 498g. It has an IP20 degree of protection. It becomes IP40 once in modular enclosure according to IEC/EN 60529 standard. The operating temperature is from -5°C to 60°C. The storage temperature is from -30°C to 70°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9D31716 dimensions and weight
Weight
Net Weight
0.556 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
