PGL36100U44A - Circuit breaker, PowerPacT P, 1000A, 3 pole, 600VAC, 18kA, lugs, Micrologic 6.0A, 80% - Schneider Electric
| Cat No. | PGL36100U44A |
| Category | MCCB |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCCB |
Back Ordered
$24,190.20
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 14 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider PGL36100U44A MCCB Technical Specification
| MCCB | |
|---|---|
| Breaking Capacity | 18kA |
| Model | Square D |
| No of Pole | 3P |
| Protection | Overload and Short Circuit |
| Rating | 1000A |
Product Details
Schneider Electric PGL36100U44A - PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Ammeter with a 6.0A trip unit and an LSIG function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has lugs on both the line and load sides. This PowerPacT P, 1000A, 3 pole, circuit breaker has an interrupting rating of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider PGL36100U44A dimensions and weight
Dimensions (L × W × H)
Length
52.07 cm
Width
30.48 cm
Height
31.24 cm
Weight
Net Weight
16.96 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric PGL36100U44A - PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units. Micrologic trip units can be interchanged in the field to allow for maximum flexibility; the basic electronic trip unit doesn't have that interchangeability. This circuit breaker has a Micrologic Interchangeable Ammeter with a 6.0A trip unit and an LSIG function. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT P circuit breakers are available in 2, 3, and 4-pole unit mount, I-Line, or drawout construction. This unit has lugs on both the line and load sides. This PowerPacT P, 1000A, 3 pole, circuit breaker has an interrupting rating of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT P circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for PGL36100U44A
The Schneider PGL36100U44A MCCB (Molded Case Circuit Breaker) is designed to provide reliable protection against overloads, short circuits, and electrical faults in industrial and commercial power distribution systems.
The Schneider PGL36100U44A MCCB features high breaking capacity, thermal magnetic or electronic trip units, wide current ratings, and compatibility with Schneider distribution panels, making it suitable for heavy duty applications.
The price of Schneider PGL36100U44A MCCB varies depending on amperage rating, pole configuration, and series type. ElectriHub offers competitive pricing for genuine Schneider MCCBs with fast delivery.
You can download the Schneider PGL36100U44A MCCB datasheet from the official Schneider Electric website or request the original PDF datasheet from ElectriHub technical support.
Yes, Schneider PGL36100U44A MCCB is widely used in industrial plants, commercial buildings, and electrical panels due to its high reliability, long service life, and strong protection performance.
Every Schneider PGL36100U44A MCCB purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCCB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCCB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
Reviews & Ratings
3.7
3 reviews
5
0
4
2
3
1
2
0
1
0
Top quality PGL36100U44A from Schneider. Installation was easy & it works as described. Happy with Electrihub service.
Used PGL36100U44A for a recent export project. Easy terminal connections, fast delivery from Electrihub to France. The build feels solid, minor complaint is with the accessory mounting. Still a top pick for panel builders.
Bought PGL36100U44A for our switchgear setup. Very reliable so far, performs consistently under varying loads. The shipment from Electrihub arrived quickly. Would recommend, only wish price was a bit lower.
