C1047E040 - trip unit MicroLogic 7.2 E for ComPacT NSX 100/160/250 circuit breakers, electronic, rating 40A, 4 poles 4d - Schneider Electric
| Cat No. | C1047E040 |
| Category | MCCB Accessories |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCCB Accessories |
Back Ordered
$1,881.35
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 22 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider C1047E040 MCCB Accessories Technical Specification
| MCCB Accessories | |
|---|---|
| Other Details | Not Aplicable |
| Range of Product | Compact NSX |
| Sub Family | Trip Unit |
| Type | Compact NSX |
Product Details
Schneider Electric C1047E040 - This MicroLogic 7.2 E (Energy) is a 4 poles 4d electronic trip unit used on ComPacT NSX 100/160/250 circuit breakers. This 40A rating electronic trip unit is an optimum choice for all standard and specific applications. It embeds adjustable long time protection against overloads. It provides also adjustable short-time protection and instantaneous protection against short-circuits. MicroLogic 7.2 E Vigi trip unit offers an integrated adjustable earth-leakage protection. MicroLogic 7.2 E indicates overloads with Alarm LEDs. The green Ready LED flashes if the circuit breaker is ready to trip. MicroLogic 7.2 E is equipped with a display module that gives energy measurement and allows fine adjustment settings. An earth leakage pre-alarm can be remotely available by installing the optional SDx module (LV429532). This product is part of our EcoStruxure Power architecture if associated with PowerTag NSX and ComPacT NSX basic frame. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider C1047E040 dimensions and weight
Dimensions (L × W × H)
Length
15 cm
Width
11 cm
Height
10 cm
Weight
Net Weight
0.795 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
