MVS40N3NW6V
Click to zoom
MVS40N3NW6V
Order on Whatsapp Schneider Electric Product Selector tool
Schneider
(No reviews yet)

MVS40N3NW6V - Circuit breaker, Easy Pact MVS, 3 Poles, 4000A, 50kA, EDO, ETV6, drawout, electrical - Schneider Electric

Cat No. MVS40N3NW6V
Category ACB
Stock In Stock
Condition Brand New, Sealed Packaging
Product Type ACB
Please contact us for the exact delivery timeline

In Stock — 1 Qty

$9,473.36
Quantity Expected Delivery
1 Units 25 Business Days

Reach out to us for project inquiries, Add to cart and click on send inquiry

Currently viewed by 18 users
Secure Payment with
Visa, MasterCard, American Express, Apple Pay, Discover, PayPal, Stripe
Need help on Inquiry? Call Us on +1 (888) 293-7436
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach

Technical Documents

No Data Available

There is no data to show you right now.

Technical Specification

Schneider MVS40N3NW6V ACB Technical Specification

ACB
Breaking Cap 50kA
Model Easy pact MVS
Pole 3P
Protection Overload, Short Circuit and Ground Fault
Rating 4000A
Type Electrical Draw-Out

Product Details

Schneider Electric MVS40N3NW6V EasyPact MVS40 is a 4000A circuit breaker. The application is suitable for 690VAC@50/60Hz. With electrical operating mechanism(220/240VAC),MCH+XF+MX, and basic trip unit with display. The breaking capacity(Icu) is 50kA@220…440V,and completed selectivity Ics=100%Icu. It provides basic protection(LSIG) , but also energy monitoring timely by metering. This version object is 3poles withdrawable type. The final product is conformed with IEC60947-2 standard, and pollution degree 4 level as IEC60664-1. The cables can be rear-connected with supply by horizontal or vertical, attached with optional accessories inside the slots. The chassis locking in connected or disconnected,also OFF-position locking by keylock. This size is 439mm(height),441mm(width),395mm(depth). We are dedicatedly involved in providing an excellent quality products at Electrihub.

Product Dimensions

Schneider MVS40N3NW6V dimensions and weight

Dimensions (L × W × H)
Length 50 cm
Width 35 cm
Height 42 cm
Weight
Net Weight 38 kg

Dimensions are approximate. For precise dimensional drawings, contact us.
