33573 - rectangular sensor for earth leakage protection, Compact NS630b to 1600, , 1600 A, inside dimensions 280 mm x 115 mm - Schneider Electric
| Cat No. | 33573 |
| Category | ACB Accessories |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | ACB Accessories |
Back Ordered
$5,265.51
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 31 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider 33573 ACB Accessories Technical Specification
| ACB Accessories | |
|---|---|
| Other Details | Not Applicable |
| Range of Product | — |
| Sub Family | Sensor Plug |
| Type | Master pact NT/NW |
Product Details
Schneider Electric 33573 - This is a rectangular sensor for earth leakage protection for Compact NS 630b to 1600 devices equipped with Micrologic 7 A/P trip unit. The sensor is installed around the busbars (phases + neutral) to detect the zero phase sequence current required for the earth-leakage protection. The operational current is up to 1600 A. The inside dimensions are 280mm (W) x 115mm (H) x 71mm (D). The external dimensions are 381mm (W) x 233mm (H) x 71mm (D). The weight is 14 Kg. The sensor is installed in the switchboard. The sensor is provided with a cable for the connection to Compact NS circuit breaker. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider 33573 dimensions and weight
Weight
Net Weight
11.199 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
