MVS40N3NW6A - Circuit breaker, Easy Pact MVS, 3 Poles, 4000A, 50kA, EDO, ETA6, drawout, electrical - Schneider Electric
| Cat No. | MVS40N3NW6A |
| Category | ACB |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | ACB |
Back Ordered
$7,381.17
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 41 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider MVS40N3NW6A ACB Technical Specification
| ACB | |
|---|---|
| Breaking Cap | 50kA |
| Model | Easy pact MVS |
| Pole | 3P |
| Protection | Overload, Short Circuit and Ground Fault |
| Rating | 4000A |
| Type | Electrical Draw-Out |
Product Details
Schneider Electric MVS40N3NW6A EasyPact MVS40N is a 4000A circuit breaker. The breaking capacity (Icu) is 50kA rms at 440VAC 50/60Hz. The operational voltage is 690VAC. This version is 3 poles drawout. Electronic trip unit provides LSIG protection include Overload, Short-time, Instantaneous and Earth fault protection. A digital LCD screen continuously displays I1, I2, I3, IN, Ig and maximeter(Imax). Fault indications LED indicate 5 types of fault which are Ir (Overload), Isd (Short time), Ii (Instantaneous), Ig (Ground fault) and Ap(Internal fault). It could be electrical operated (200/240V AC) with gear motor, closing release and opening release. EasyPact MVS is compliant with international standards (IEC 60947, CE, EAC and RoHS). The dimension is 439mm x 441mm x 395mm (H x W x D).
We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
No Data Available
There is no data to show you right now.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric MVS40N3NW6A EasyPact MVS40N is a 4000A circuit breaker. The breaking capacity (Icu) is 50kA rms at 440VAC 50/60Hz. The operational voltage is 690VAC. This version is 3 poles drawout. Electronic trip unit provides LSIG protection include Overload, Short-time, Instantaneous and Earth fault protection. A digital LCD screen continuously displays I1, I2, I3, IN, Ig and maximeter(Imax). Fault indications LED indicate 5 types of fault which are Ir (Overload), Isd (Short time), Ii (Instantaneous), Ig (Ground fault) and Ap(Internal fault). It could be electrical operated (200/240V AC) with gear motor, closing release and opening release. EasyPact MVS is compliant with international standards (IEC 60947, CE, EAC and RoHS). The dimension is 439mm x 441mm x 395mm (H x W x D).
We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for MVS40N3NW6A
Schneider ACB MVS40N3NW6A is used for low-voltage power distribution and protection of electrical systems. It provides high breaking capacity, adjustable trip settings, and ensures system reliability in industrial and commercial networks.
The technical specifications of MVS40N3NW6A include rated current, breaking capacity, poles, trip unit type (Micrologic), operational voltage, mechanical endurance, and mounting dimensions. It complies with IEC standards for LV switchgear.
Yes, MVS40N3NW6A is suitable for industrial facilities, data centers, commercial buildings, and critical infrastructure thanks to its high reliability, fault protection, and configurable protection settings.
MVS40N3NW6A offers adjustable overload, short-circuit, and earth-fault protection via its Micrologic trip unit. It monitors current continuously and disconnects the circuit instantly during fault conditions.
Installation of MVS40N3NW6A requires proper alignment, secure busbar or cable connections, appropriate tightening torque, periodic maintenance, and adherence to Schneider LV switchgear guidelines.
The price of MVS40N3NW6A varies by distributor, specifications, and region. Electrihub provides up to date pricing, availability, and offers for MVS40N3NW6A.
The technical datasheet for MVS40N3NW6A includes detailed electrical ratings, protection curves, Micrologic trip unit characteristics, dimensions, wiring diagrams, and compliance standards used for engineering and panel design.
Every Schneider MVS40N3NW6A ACB purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right ACB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right ACB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The price of Schneider MVS40N3NW6A ACB depends on specifications, availability, and market conditions. You can check the latest GST-inclusive price on Electrihub India, which provides genuine products, transparent billing, and PAN India delivery.
