HDA260704 - Circuit breaker, PowerPacT H, 70A, 2 pole, 600VAC, 14kA, I-Line, thermal magnetic, 80%, BC - Schneider Electric
| Cat No. | HDA260704 |
| Category | MCCB |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCCB |
Back Ordered
$1,951.38
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 27 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider HDA260704 MCCB Technical Specification
| MCCB | |
|---|---|
| Breaking Capacity | 14KA |
| Model | Square D |
| No of Pole | 2P |
| Protection | Overload and Short Circuit |
| Rating | 70A |
Product Details
Schneider Electric HDA260704 - PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 70A, 2 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80% with a BC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider HDA260704 dimensions and weight
Dimensions (L × W × H)
Length
37.15 cm
Width
20.64 cm
Height
9.84 cm
Weight
Net Weight
1.361 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric HDA260704 - PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 14kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 70A, 2 pole, circuit breaker has a breaking capacity of 14kA at 600VAC. This circuit breaker has a continuous current rating of 80% with a BC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for HDA260704
The Schneider HDA260704 MCCB (Molded Case Circuit Breaker) is designed to provide reliable protection against overloads, short circuits, and electrical faults in industrial and commercial power distribution systems.
The Schneider HDA260704 MCCB features high breaking capacity, thermal magnetic or electronic trip units, wide current ratings, and compatibility with Schneider distribution panels, making it suitable for heavy duty applications.
The price of Schneider HDA260704 MCCB varies depending on amperage rating, pole configuration, and series type. ElectriHub offers competitive pricing for genuine Schneider MCCBs with fast delivery.
You can download the Schneider HDA260704 MCCB datasheet from the official Schneider Electric website or request the original PDF datasheet from ElectriHub technical support.
Yes, Schneider HDA260704 MCCB is widely used in industrial plants, commercial buildings, and electrical panels due to its high reliability, long service life, and strong protection performance.
Every Schneider HDA260704 MCCB purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCCB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCCB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
