EZ9F71463 - Miniature circuit breaker, Easy9, 4P, 63 A, C curve, 10000 A - Schneider Electric
| Cat No. | EZ9F71463 |
| Category | MCB |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB |
In Stock — 100 Qty
$57.57
| Quantity | Expected Delivery |
|---|---|
| 100 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 31 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider EZ9F71463 MCB Technical Specification
| MCB | |
|---|---|
| Breaking Cap | 10kA |
| Curve | C |
| Model | EZ9 |
| No of pole | 4P |
| Range of Product | — |
| Rating | 63A |
Product Details
Schneider Electric EZ9F71463 - This Easy9 product is a low voltage miniature circuit breaker (MCB),It is a 4P circuit breaker with 4 protected poles and 63A In rated current and C tripping curve,The Icn rated short circuit breaking capacity is up to 10000A at 415VAC conforming to EN/IEC 60898-1 standard,It is compliant with IEC 60898-1 standard,This product has a protection against short circuit and a protection of cable against overloads,It has a fault tripping indication on the front panel by the position of the handle (O-I engraved),This product is dedicated for residential and small commercial buildings,It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles,The Ue operational voltage is 415VAC. The Ui rated insulation voltage is 500VAC,The Uimp rated impulse withstand voltage is 4kV. The operating frequency is 50Hz or 60Hz,It can be mounted on DIN rail for modular installation. Its width is 8 pitches of 9mm,The product colour is light grey (RAL7035). The dimensions are (W) 72mm x (H) 81mm x (D) 77.5mm. The weight is 0.51kg,According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure,The operating temperature is -5°C to 55°C. The storage temperature is -25°C to 85°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider EZ9F71463 dimensions and weight
Dimensions (L × W × H)
Length
8.6 cm
Width
7.8 cm
Height
7.4 cm
Weight
Net Weight
0.46 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric EZ9F71463 - This Easy9 product is a low voltage miniature circuit breaker (MCB),It is a 4P circuit breaker with 4 protected poles and 63A In rated current and C tripping curve,The Icn rated short circuit breaking capacity is up to 10000A at 415VAC conforming to EN/IEC 60898-1 standard,It is compliant with IEC 60898-1 standard,This product has a protection against short circuit and a protection of cable against overloads,It has a fault tripping indication on the front panel by the position of the handle (O-I engraved),This product is dedicated for residential and small commercial buildings,It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles,The Ue operational voltage is 415VAC. The Ui rated insulation voltage is 500VAC,The Uimp rated impulse withstand voltage is 4kV. The operating frequency is 50Hz or 60Hz,It can be mounted on DIN rail for modular installation. Its width is 8 pitches of 9mm,The product colour is light grey (RAL7035). The dimensions are (W) 72mm x (H) 81mm x (D) 77.5mm. The weight is 0.51kg,According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure,The operating temperature is -5°C to 55°C. The storage temperature is -25°C to 85°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for EZ9F71463
Schneider MCB EZ9F71463 offers high breaking capacity depending on its pole and rating. You can check exact kA rating using ElectriHub MCB filters such as poles, current rating, and curve type.
Yes, Schneider MCB EZ9F71463 is designed for home distribution systems and ensures protection against overload and short circuits. Select your pole and ampere rating from the ElectriHub MCB filter.
Schneider MCB EZ9F71463 is available in B, C, and D curve options depending on the application. Use the curve filter on ElectriHub to verify available options.
To select the right ampere rating for Schneider MCB EZ9F71463, check your load requirement and matching poles. ElectriHub rating filter helps you choose from 1A to 63A.
Yes, Schneider MCB EZ9F71463 supports standard DIN rail mounting for easy installation in all household and industrial panels.
Every Schneider EZ9F71463 MCB purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
