A9KF71210 - Acti9 K60H 2P - 10 A - C curve 10000 A - Schneider Electric
| Cat No. | A9KF71210 |
| Category | MCB |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB |
In Stock — 182 Qty
$21.54
| Quantity | Expected Delivery |
|---|---|
| 182 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 46 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9KF71210 MCB Technical Specification
| MCB | |
|---|---|
| Breaking Cap | 10kA |
| Curve | C |
| Model | A9K |
| No of pole | 2P |
| Range of Product | — |
| Rating | 10A |
Product Details
Schneider Electric A9KF71210 - This Acti9 K60H product is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles and 10A In rated current and C tripping curve. The rated short circuit breaking capacity goes up to 10kA at 415VAC conforming to EN 60898-1 standard and at conforming to standard. This product is compliant with EN/IEC 60898-1 standard. This miniature circuit breaker protects circuit against short circuit and overload current. The connection can be made downstream by biconnect comb busbar. It can be also made upstream/downstream by tunnel terminals. A padlock device is available for work to be carried out on live parts. It has an electrical endurance going up to 20000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 4kV. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 4 pitches of 9mm. The product colour is white (RAL9003). The dimensions are (W) 36mm x (H) 81mm x (D) 70mm. The weight is 0.24kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -5°C to 55°C. The storage temperature is -25°C to 85°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9KF71210 dimensions and weight
Dimensions (L × W × H)
Length
7 cm
Width
3.6 cm
Height
8.1 cm
Weight
Net Weight
0.24 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric A9KF71210 - This Acti9 K60H product is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles and 10A In rated current and C tripping curve. The rated short circuit breaking capacity goes up to 10kA at 415VAC conforming to EN 60898-1 standard and at conforming to standard. This product is compliant with EN/IEC 60898-1 standard. This miniature circuit breaker protects circuit against short circuit and overload current. The connection can be made downstream by biconnect comb busbar. It can be also made upstream/downstream by tunnel terminals. A padlock device is available for work to be carried out on live parts. It has an electrical endurance going up to 20000 cycles and a mechanical endurance going up to 20000 cycles. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 4kV. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 4 pitches of 9mm. The product colour is white (RAL9003). The dimensions are (W) 36mm x (H) 81mm x (D) 70mm. The weight is 0.24kg. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -5°C to 55°C. The storage temperature is -25°C to 85°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for A9KF71210
Every Schneider A9KF71210 MCB purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right MCB for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Schneider MCB A9KF71210 offers high breaking capacity depending on its pole and rating. You can check exact kA rating using ElectriHub MCB filters such as poles, current rating, and curve type.
Yes, Schneider MCB A9KF71210 is designed for home distribution systems and ensures protection against overload and short circuits. Select your pole and ampere rating from the ElectriHub MCB filter.
Schneider MCB A9KF71210 is available in B, C, and D curve options depending on the application. Use the curve filter on ElectriHub to verify available options.
To select the right ampere rating for Schneider MCB A9KF71210, check your load requirement and matching poles. ElectriHub rating filter helps you choose from 1A to 63A.
Yes, Schneider MCB A9KF71210 supports standard DIN rail mounting for easy installation in all household and industrial panels.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
The breaking capacity of the Schneider A9KF71210 MCB is specifically rated to handle high fault currents (typically 6kA or 10kA depending on the specific variant) to prevent damage to the downstream equipment.
The Schneider A9KF71210 is typically rated for standard AC voltages (up to 240V for single-phase or 415V for three-phase systems), making it compatible with most standard power grids.
Yes, the Schneider A9KF71210 is versatile and suitable for both residential load centers and commercial distribution panels, provided the electrical specifications match your system requirements.
Depending on the specific configuration of the A9KF71210 series, it is available in various pole configurations such as SP, DP, TP, or FP to suit different circuit requirements.
The Schneider A9KF71210 MCB is primarily designed to protect electrical circuits from overcurrents caused by overloads and short circuits in MCB-based installations.
