XB5AA55 - Push button, Harmony XB5, yellow flush complete pushbutton 22mm spring return 1NO+1NC unmarked - Schneider Electric
| Cat No. | XB5AA55 |
| Category | Push Button |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | Push Button |
In Stock — 6 Qty
$31.46
| Quantity | Expected Delivery |
|---|---|
| 6 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 15 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider XB5AA55 Push Button Technical Specification
| Push Button | |
|---|---|
| Color | Yellow |
| Elements | 1NO+1NC |
| Illumination | Illuminated |
| Lockable | No |
| Mounting | Flush |
| Range of Product | — |
| Size | 22mm |
| Sub Type | Spring Return |
| Type | XB5 |
Product Details
Schneider Electric XB5AA55 - This Harmony XB5, flush modular yellow push button operates with a spring return / impulse mechanism and uses screw-clamp terminals. This push button provides a simple and robust control to machines and processes. It is easily installed into standard 22mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. Its schematic is clearly distinguishable thanks to clear colors, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider XB5AA55 dimensions and weight
Dimensions (L × W × H)
Length
8.8 cm
Width
5.5 cm
Height
3.5 cm
Weight
Net Weight
0.046 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric XB5AA55 - This Harmony XB5, flush modular yellow push button operates with a spring return / impulse mechanism and uses screw-clamp terminals. This push button provides a simple and robust control to machines and processes. It is easily installed into standard 22mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. Its schematic is clearly distinguishable thanks to clear colors, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for XB5AA55
Every Schneider XB5AA55 Push Button purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Push Button for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Push Button for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
Schneider Electric XB5AA55 is a 22.5 mm modular plastic push button / operator (Harmony XB5 series) engineered with double-insulated thermoplastic construction. It operates at voltages up to 415V/600V AC (50 Hz) with a 10A thermal current (Ith) rating conforming to IS/IEC 60947-5-1 (utilization categories AC-15: 3A at 240V, 1.2A at 415V) for Indian automation panels.
The XB5AA55 push button is certified to IP66, IP67, IP69, and IP69K (IS/IEC 60529) and IK05 impact resistance, shielding internal contact elements from moisture, monsoonal condensation, airborne chemical vapors, and industrial washdowns in Indian manufacturing plants.
Available in 1NO, 1NC, 2NO, 2NC, or 1NO+1NC arrangements with standard screw-clamp terminals, XB5AA55 features positive opening NC contacts (IEC 60947-5-1 Annex K) that guarantee physical contact separation even under contact weld conditions for fail-safe emergency stopping.
Engineered for high-duty cycling, XB5AA55 delivers a mechanical lifespan of up to 10 million operating cycles (for standard spring-return push buttons) and an electrical endurance of over 1 million operations at rated AC-15 load, ensuring years of maintenance-free service.
Procure genuine Schneider Electric XB5AA55 on Electrihub India. Electrihub India ensures factory-certified stock, official manufacturer warranties, HSN-compliant 18% GST tax invoices for commercial input credits, and prompt nationwide dispatch.
The Schneider Electric XB5AA55 belongs to the Harmony XB2/XB4/XB5/XB6/XB7 22 mm modular pushbutton range, and it installs into a 22 mm (22.5 mm nominal) round panel cutout conforming to EN/IEC 60947-1, the same footprint used across the whole Harmony platform for easy retrofit. Checking this cutout size before ordering avoids rework on an already-drilled control panel, and because the dimension follows an internationally recognised standard, panels designed in one country can be fitted with the XB5AA55 sourced from another without modifying the enclosure.
The Schneider Electric XB5AA55 is rated at IP66, IP67, IP69K and (on the metal XB4 range) up to IP69K wash-down protection, making it dust-tight and resistant to high-pressure and high-temperature jet cleaning. This level of sealing is what determines whether the device can be specified for washdown areas, outdoor enclosures, dusty workshops or humid coastal sites, so it is one of the first specifications engineers in any country check when matching a pushbutton to its installation environment.
The Schneider Electric XB5AA55 is manufactured to EN/IEC 60947-1 and EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 No. 14, UL 508 and JIS C4520, so it can be legally specified on panels built to European, North American, Canadian and Japanese electrical codes. Holding recognised IEC, UL, CSA and CE approvals together (rather than just one regional mark) is what lets the same part number be specified on machinery and switchgear panels built for the EU, North America, the Middle East, Africa and Asia-Pacific, without needing a region-specific substitute.
The Schneider Electric XB5AA55 offers a rated insulation voltage of up to 600 V (metal XB4 range) or 250 V (plastic/compact ranges), with a rated operational current of roughly 0.1–6 A depending on the AC-15/DC-13 contact block fitted (commonly 1 NO, 1 NC, 1 NO+1 NC or 2 NO). Confirming the rated voltage, current and contact configuration against the control circuit it will switch is essential, since undersizing the contact block against the connected load is one of the most common causes of premature pushbutton failure in the field.
The Schneider Electric XB5AA55 is rated for an ambient operating range of -25°C to +70°C, with an electrical/mechanical durability of several hundred thousand to over a million operations, and an 18-month manufacturer warranty on the complete unit. This combination of climate range and cycle life is what allows the same push button to be deployed in cold-storage plants, standard factory floors and hot, humid outdoor installations across different climate zones without a separate temperature-rated variant.
Reviews & Ratings
5.0
4 reviews
5
4
4
0
3
0
2
0
1
0
Procured a batch of XB5AA55 push buttons for our automated assembly fixtures. Pricing was significantly more competitive than our regular regional suppliers, and all units were verified 100% original Schneider. Electrihub is now on our approved vendor list.
Top-notch Schneider quality as expected. Switch contacts are crisp, housing is flame-retardant, and mounting collar locks firmly in place. Will definitely continue ordering our industrial automation supplies from Electrihub.
Had an emergency breakdown on our conveyor line due to a damaged button. Ordered the Schneider XB5AA55 on Electrihub India and it reached us within 48 hours. Plug-and-play replacement, machine was back up in no time. Great service.
The mechanical action on the Schneider XB5AA55 is very responsive and positive. Terminal blocks seat firmly and fit standard 22.5mm panel knockouts cleanly. Sourcing automation hardware through Electrihub was straightforward and cost-effective.
