XB4BK123M5 - Illuminated selector switch, Harmony XB4, metal, green handle, 22mm, universal LED, 2 positions, 1NO + 1NC, 230...240V AC - Schneider Electric
| Cat No. | XB4BK123M5 |
| Category | Push Button |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | Push Button |
In Stock — 4 Qty
$124.43
| Quantity | Expected Delivery |
|---|---|
| 4 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 31 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider XB4BK123M5 Push Button Technical Specification
| Push Button | |
|---|---|
| Color | Green |
| Elements | 1NO+1NC |
| Illumination | Illuminated |
| Lockable | No |
| Mounting | - |
| Range of Product | — |
| Size | 22mm |
| Sub Type | - |
| Type | XB4 |
Product Details
Schneider Electric XB4BK123M5 - This Harmony XB4 illuminated modular green selector switch has 2 positions, operates with a stay-put mechanism, a 230V to 240V AC integral LED,It has a metal bezel,This illuminated selector switch provides a versatile and highly visible interface for controlling your machines,It is easily installed into standard 22mm diameter cut-outs and connected to your control circuits with simple screw-clamp connections,It provides a clear help in setting your machines in various operating modes, even in darker control rooms, and with a clear visual feedback,It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider XB4BK123M5 dimensions and weight
Dimensions (L × W × H)
Length
9.1 cm
Width
5.4 cm
Height
3.9 cm
Weight
Net Weight
0.109 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric XB4BK123M5 - This Harmony XB4 illuminated modular green selector switch has 2 positions, operates with a stay-put mechanism, a 230V to 240V AC integral LED,It has a metal bezel,This illuminated selector switch provides a versatile and highly visible interface for controlling your machines,It is easily installed into standard 22mm diameter cut-outs and connected to your control circuits with simple screw-clamp connections,It provides a clear help in setting your machines in various operating modes, even in darker control rooms, and with a clear visual feedback,It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for XB4BK123M5
Every Schneider XB4BK123M5 Push Button purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Push Button for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Push Button for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
Schneider Electric XB4BK123M5 is an industrial 22.5 mm chromium-plated metallic push button (Harmony XB4 series) rated for operational voltages up to 415V/600V AC (50 Hz) and a conventional free air thermal current (Ith) of 10A compliant with IS/IEC 60947-5-1 (AC-15: 240V/3A, 415V/1.2A; DC-13: 250V/0.27A) for heavy industrial switchboards across India.
Equipped with a solid metal bezel and precision elastomer seal, XB4BK123M5 achieves IP66, IP67, IP69, and IP69K ingress protection compliant with IS/IEC 60529, along with IK06 mechanical impact resistance, ensuring total protection against oil, coolants, cement dust, and high-pressure steam cleaning.
Illuminated configurations of XB4BK123M5 feature an integral protected LED lamp head operating at standard Indian industrial control voltages (24V AC/DC, 110V AC, or 230V AC, 50 Hz), delivering vibrant optical signaling with a service lifespan exceeding 100,000 hours under fluctuating grid conditions.
Featuring a standardized 22.5 mm cutout footprint with an anti-rotation locating lug and a single screw-locking metal collar bracket, XB4BK123M5 guarantees rigid, vibration-proof alignment in Indian motor control centers (MCC), power control centers (PCC), and operator desks.
Source authentic Schneider Electric XB4BK123M5 push buttons directly from Electrihub India. Electrihub India guarantees genuine products, manufacturer test reports, 18% GST input credit invoices, and express delivery across Delhi NCR, Pune, Mumbai, Chennai, Bengaluru, and Ahmedabad.
The Schneider Electric XB4BK123M5 belongs to the Harmony XB2/XB4/XB5/XB6/XB7 22 mm modular pushbutton range, and it installs into a 22 mm (22.5 mm nominal) round panel cutout conforming to EN/IEC 60947-1, the same footprint used across the whole Harmony platform for easy retrofit. Checking this cutout size before ordering avoids rework on an already-drilled control panel, and because the dimension follows an internationally recognised standard, panels designed in one country can be fitted with the XB4BK123M5 sourced from another without modifying the enclosure.
The Schneider Electric XB4BK123M5 is rated at IP66, IP67, IP69K and (on the metal XB4 range) up to IP69K wash-down protection, making it dust-tight and resistant to high-pressure and high-temperature jet cleaning. This level of sealing is what determines whether the device can be specified for washdown areas, outdoor enclosures, dusty workshops or humid coastal sites, so it is one of the first specifications engineers in any country check when matching a pushbutton to its installation environment.
The Schneider Electric XB4BK123M5 is manufactured to EN/IEC 60947-1 and EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 No. 14, UL 508 and JIS C4520, so it can be legally specified on panels built to European, North American, Canadian and Japanese electrical codes. Holding recognised IEC, UL, CSA and CE approvals together (rather than just one regional mark) is what lets the same part number be specified on machinery and switchgear panels built for the EU, North America, the Middle East, Africa and Asia-Pacific, without needing a region-specific substitute.
The Schneider Electric XB4BK123M5 offers a rated insulation voltage of up to 600 V (metal XB4 range) or 250 V (plastic/compact ranges), with a rated operational current of roughly 0.1–6 A depending on the AC-15/DC-13 contact block fitted (commonly 1 NO, 1 NC, 1 NO+1 NC or 2 NO). Confirming the rated voltage, current and contact configuration against the control circuit it will switch is essential, since undersizing the contact block against the connected load is one of the most common causes of premature pushbutton failure in the field.
The Schneider Electric XB4BK123M5 is rated for an ambient operating range of -25°C to +70°C, with an electrical/mechanical durability of several hundred thousand to over a million operations, and an 18-month manufacturer warranty on the complete unit. This combination of climate range and cycle life is what allows the same push button to be deployed in cold-storage plants, standard factory floors and hot, humid outdoor installations across different climate zones without a separate temperature-rated variant.
