XB2BA11C - Complete push button, Easy Harmony XB2, metal, flush, white, 22mm, spring return, unmarked, 1NO - Schneider Electric
| Cat No. | XB2BA11C |
| Category | Push Button |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | Push Button |
In Stock — 1 Qty
$5.54
| Quantity | Expected Delivery |
|---|---|
| 1 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 12 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider XB2BA11C Push Button Technical Specification
| Push Button | |
|---|---|
| Color | White |
| Elements | 1NO |
| Illumination | Non-Illuminated |
| Lockable | No |
| Mounting | Flush |
| Range of Product | XB2 |
| Size | 22mm |
| Sub Type | Complete push-button |
| Type | XB2 |
Product Details
Schneider Electric XB2BA11C - This complete push-button provides an ergonomic interface for controlling your marchine. It is easily installed and into a standard 22mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration, high pressure washer and dust resistant thanks to its IP65 protection, making it ideal for operation in harsh environments. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider XB2BA11C dimensions and weight
Dimensions (L × W × H)
Length
5.45 cm
Width
4 cm
Height
3 cm
Weight
Net Weight
0.07 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric XB2BA11C - This complete push-button provides an ergonomic interface for controlling your marchine. It is easily installed and into a standard 22mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration, high pressure washer and dust resistant thanks to its IP65 protection, making it ideal for operation in harsh environments. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for XB2BA11C
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
Schneider Electric XB2BA11C is a heavy-duty 22 mm metallic push button (Harmony XB2B series) widely deployed across Indian power plants, steel mills, cement factories, and LT switchgear panels. Rated up to 415V/600V AC (50 Hz) and 10A thermal current (Ith), it complies with IS/IEC 60947-5-1 (AC-15: 240V/3A, 415V/1.2A).
Featuring a solid zinc alloy metal body and chrome-plated bezel, XB2BA11C delivers IP65 ingress protection (IS/IEC 60529) and IK06 mechanical impact resistance, withstanding extreme mechanical abuse, hot oil splashes, conductive dust, and heavy industrial shopfloor environments.
Depending on the model (e.g., flush spring-return, boot-guarded, mushroom emergency stop, or illuminated), XB2BA11C provides 1NO, 1NC, or 2NO/NC contact blocks with positive opening action and push-pull or turn-to-release latching compliant with IS/IEC 60947-5-5.
Designed for standard 22.2 mm panel cutouts with an anti-turn notch, XB2BA11C locks firmly in place using a rear threaded retaining ring, preventing loosening caused by repeated high-force manual actuation on machine operating panels.
Original Schneider Electric XB2BA11C push buttons can be procured on Electrihub India. Electrihub India guarantees factory-certified parts, full 18% GST tax invoices for input tax credit, and expedited Pan-India logistics.
The Schneider Electric XB2BA11C belongs to the Harmony XB2/XB4/XB5/XB6/XB7 22 mm modular pushbutton range, and it installs into a 22 mm (22.5 mm nominal) round panel cutout conforming to EN/IEC 60947-1, the same footprint used across the whole Harmony platform for easy retrofit. Checking this cutout size before ordering avoids rework on an already-drilled control panel, and because the dimension follows an internationally recognised standard, panels designed in one country can be fitted with the XB2BA11C sourced from another without modifying the enclosure.
The Schneider Electric XB2BA11C is rated at IP66, IP67, IP69K and (on the metal XB4 range) up to IP69K wash-down protection, making it dust-tight and resistant to high-pressure and high-temperature jet cleaning. This level of sealing is what determines whether the device can be specified for washdown areas, outdoor enclosures, dusty workshops or humid coastal sites, so it is one of the first specifications engineers in any country check when matching a pushbutton to its installation environment.
The Schneider Electric XB2BA11C is manufactured to EN/IEC 60947-1 and EN/IEC 60947-5-1, EN/IEC 60947-5-4, CSA C22.2 No. 14, UL 508 and JIS C4520, so it can be legally specified on panels built to European, North American, Canadian and Japanese electrical codes. Holding recognised IEC, UL, CSA and CE approvals together (rather than just one regional mark) is what lets the same part number be specified on machinery and switchgear panels built for the EU, North America, the Middle East, Africa and Asia-Pacific, without needing a region-specific substitute.
The Schneider Electric XB2BA11C offers a rated insulation voltage of up to 600 V (metal XB4 range) or 250 V (plastic/compact ranges), with a rated operational current of roughly 0.1–6 A depending on the AC-15/DC-13 contact block fitted (commonly 1 NO, 1 NC, 1 NO+1 NC or 2 NO). Confirming the rated voltage, current and contact configuration against the control circuit it will switch is essential, since undersizing the contact block against the connected load is one of the most common causes of premature pushbutton failure in the field.
The Schneider Electric XB2BA11C is rated for an ambient operating range of -25°C to +70°C, with an electrical/mechanical durability of several hundred thousand to over a million operations, and an 18-month manufacturer warranty on the complete unit. This combination of climate range and cycle life is what allows the same push button to be deployed in cold-storage plants, standard factory floors and hot, humid outdoor installations across different climate zones without a separate temperature-rated variant.
