MEHVBHDY224A48 - Varplus Box Heavy Duty MPP-HDuty - 3-phase delta connection - 26.9 kVAr - 480 V - Schneider Electric

Cat No.	MEHVBHDY224A48
Category	Capacitors
Stock	In Stock
Condition	Brand New, Sealed Packaging
Product Type	Capacitors

Please contact us for the exact delivery timeline

In Stock — 2 Qty

$242.70

Quantity	Expected Delivery
2 Units	25 Business Days

Reach out to us for project inquiries, Add to cart and click on send inquiry

Currently viewed by 47 users

Secure Payment with

Visa, MasterCard, American Express, Apple Pay, Discover, PayPal, Stripe

Need help on Inquiry? Call Us on +1 (888) 293-7436

Warranty Guarantee

100% Original Products

EEE Buyer Protection

World-Wide Reach

Technical Documents

No Data Available

There is no data to show you right now.

Technical Specification

Schneider MEHVBHDY224A48 Capacitors Technical Specification

Capacitors
Duty	Heavy Duty
Phase	3
Rated Voltage	480V
Rating Kvar	22.4
Type	Box-Type

Product Details

Schneider MEHVBHDY224A48 - MPP-H Duty Box 22.4 kvar 480V 3Ph 50Hz This Compact Capacitor is Designed to optimize space and Power Factor Correcction.It is an optimal choice for all standard .This version comes with a variety of optional function Capacitor and accessories.It is compliant with international standards (IEC 60947), CCC, EAC .It is part of Schneider Electric EcoStruxure Power architecture. We are dedicatedly involved in providing an excellent quality products at Electrihub.

Product Dimensions

Schneider MEHVBHDY224A48 dimensions and weight

Dimensions (L × W × H)

Length 37 cm

Width 32 cm

Height 17.5 cm

Weight

Net Weight 8.16 kg

Dimensions are approximate. For precise dimensional drawings, contact us.

Frequently Bought Together

No Data Available

There is no data to show you right now.

Product Line Card

No Data Available

There is no data to show you right now.

Alternate Products

Product Overview

Frequently Asked Questions for MEHVBHDY224A48

Every Schneider MEHVBHDY224A48 Capacitors purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging ‚Äî ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Capacitors for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.

Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.

Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.

Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.

The Schneider Electric MEHVBHDY224A48 is an industrial 3-phase low voltage power factor correction capacitor rated at 22.4 kVAr at 480V AC, 50/60 Hz. Designed for international installations, it complies fully with global IEC 60831-1 and IEC 60831-2 standards (as well as UL/CSA certifications where applicable). It features an enclosure type of Box (Modular Sheet Steel Enclosure) under the VarPlus Heavy Duty (MPP - Metallized Polypropylene) architecture. The rated nominal phase current is approximately 26.94 A, engineered to operate across standard industrial ambient temperatures (-25°C to +55°C, Class D) with low dielectric dissipation losses (≤0.2 W/kVAr to 0.5 W/kVAr). Electrihub supplies this genuine Schneider unit with manufacturer test compliance for worldwide export.

The Schneider Electric MEHVBHDY224A48 is rated at 480V AC, making it specifically optimized for 400V/415V nominal electrical networks equipped with 7% (189 Hz) detuned harmonic filter reactors. Under a 400V grid, this capacitor delivers an effective output of ~15.56 kVAr (or ~16.74 kVAr at 415V), perfectly counteracting harmonic amplification and resonance from non-linear loads like VFDs and rectifiers. Engineered with enhanced dielectric withstand capability, it safely handles continuous overcurrents up to 1.5–1.8 times rated current (In) and substantial current crest factors. For facilities with harmonic pollution exceeding IEEE 519 thresholds, Electrihub technical engineers recommend configuring the MEHVBHDY224A48 alongside appropriately matched Schneider detuned iron-core reactors to prevent parallel resonance.

The MEHVBHDY224A48 utilizes specialized zinc-aluminium metallized polypropylene (MPP) dry resin-filled technology enclosed in a robust sheet-steel box. It incorporates wave-cut film edges to eliminate edge field stress and ensure long dielectric operational life. It features an integrated 3-phase overpressure disconnector mechanism that mechanically isolates all three phases simultaneously in the event of internal fault pressure buildup, preventing case rupture. Additionally, self-healing dielectric properties vaporize microscopic localized breakdowns within microseconds without interrupting service, while factory-fitted discharge resistors reduce terminal residual voltage to below 50V within 60 seconds of disconnection as required by IEC standards.

The Schneider MEHVBHDY224A48 (22.4 kVAr) is designed for seamless mounting in modular APFC capacitor banks, fixed motor compensation, and MCC switchboards. When installed in switched stages, it should be controlled by capacitor-duty contactors (such as Schneider TeSys LC1D•K with early-make damping resistors) or static thyristor switching modules (such as Schneider Classica/Varlogic switches) to suppress severe switching inrush transients (up to 200x–250x In). Panel designers should maintain minimum 30–50 mm clearances around the unit for convection cooling, and connect via properly rated flexible copper cabling to prevent terminal mechanical stress.

Electrihub (electrihub.com) is a premier global distributor of authentic Schneider Electric power quality and switchgear solutions. When you source the MEHVBHDY224A48 from Electrihub, you receive 100% brand-new, factory-sealed components complete with full manufacturer serial traceability, global export packaging, technical compliance datasheets, and standard manufacturer warranty. Electrihub delivers competitive pricing, technical sizing support for APFC integration across North America, Europe, the Middle East, and Asia-Pacific, and fast worldwide logistics.

Reviews & Ratings

4.8

5 reviews

Your Rating *

Your Name *

Email (optional, not published)

Review Title

Your Review *

Bhavin Mittal Sep 18, 2026

Installed this Schneider MEHVBHDY224A48 capacitor in our textile unit's main distribution board. Sourced directly via Electrihub India to replace older degraded capacitors. Electrical losses are minimal, and our plant power factor immediately improved. Outstanding electrical performance from Schneider.

Jaswinder Garg Sep 18, 2026

There are plenty of duplicate and reconditioned capacitors floating in local wholesale markets, which are a major fire hazard. We bought the Schneider MEHVBHDY224A48 from Electrihub India specifically for genuine OEM assurance. The capacitor arrived in tamper-proof factory packaging with original manufacturer test markings and warranty.

Chirag Menon Sep 18, 2026

Local switchgear stockists were quoting a 3 to 4-week delivery timeline for Schneider MEHVBHDY224A48. Found ready stock on Electrihub India and received delivery within 48 hours. Moreover, the B2B GST tax invoice was generated instantly with full input tax credit claim. Outstanding service from Electrihub.in.

Amanda L Nov 3, 2025

Installed easily, no issues, works like a charm.

Ethan N Nov 3, 2025

Installed the Schneider capacitor in our distribution system and saw immediate improvement in power factor. Easy installation and reliable operation.
