LV481504 - Switch disconnector fuse, FuPact GSC32, 32 A, 4 poles, fuse type NFC 10 x 38 mm, front and right side control - Schneider Electric
| Cat No. | LV481504 |
| Category | Switch Fuse Unit |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | Switch Fuse Unit |
Back Ordered
$226.40
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 45 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider LV481504 Switch Fuse Unit Technical Specification
| Switch Fuse Unit | |
|---|---|
| Execution | Not Applicable |
| Mounting | DIN |
| Pole | 4P |
| Rating | 32A |
Product Details
Schneider Electric LV481504 - This device FuPacT GSC32 is a 4 poles switch disconnector fuse with front and right side control. It is dedicated to buildings, infrastructure and Industrial plants. It protects against short-circuits and overloads on distribution circuits. For AC22A/AC23A utilisation categories, the rated operational current is 32A at 690VAC. FuPacT GSC32 has to be used with NFC cylindrical fuse links size 10x38mm. It can be equipped with a direct frontal handle, or with an external front or right side mounting rotary handle. Extended rotary handles can be used with different shaft dimensions (200mm, 320mm or 400mm). FuPacT GSC32 in 4 poles version can also be equipped with auxiliary contacts. It complies with IEC 60947-1 and IEC 60947-3 standards. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider LV481504 dimensions and weight
Dimensions (L × W × H)
Length
11.7 cm
Width
10.5 cm
Height
9 cm
Weight
Net Weight
0.497 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric LV481504 - This device FuPacT GSC32 is a 4 poles switch disconnector fuse with front and right side control. It is dedicated to buildings, infrastructure and Industrial plants. It protects against short-circuits and overloads on distribution circuits. For AC22A/AC23A utilisation categories, the rated operational current is 32A at 690VAC. FuPacT GSC32 has to be used with NFC cylindrical fuse links size 10x38mm. It can be equipped with a direct frontal handle, or with an external front or right side mounting rotary handle. Extended rotary handles can be used with different shaft dimensions (200mm, 320mm or 400mm). FuPacT GSC32 in 4 poles version can also be equipped with auxiliary contacts. It complies with IEC 60947-1 and IEC 60947-3 standards. We are dedicatedly involved in providing an excellent quality products at Electrihub.
