LUFV2 - Function module, TeSys U, indication of motor load 4...20 mA - Schneider Electric
| Cat No. | LUFV2 |
| Category | MPCB Accessories |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | MPCB Accessories |
In Stock — 2 Qty
$396.13
| Quantity | Expected Delivery |
|---|---|
| 2 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 23 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider LUFV2 MPCB Accessories Technical Specification
| MPCB Accessories | |
|---|---|
| Other Details | 4-20mA |
| Range of Product | — |
| Sub Family | Function Module |
| Type | TeSys U |
Product Details
Schneider Electric LUFV2 - TeSys U additional function module to be inserted in advanced power bases LUB120, LUB320, LUB380 for motor load monitoring. It provides a 4-20mA output signal, image of the load ratio, to be connected to a load impedance 100 Ohm typical (500 Ohm max). It measures the phase currents and computes the ratio I average/Ir ratio within the range of 0 to 2 for LUCB and LUCD, and of 0 to 3 for LUCC control units. It requires an external power supply 24V DC. To be inserted in the cavity of a power base provided for the auxiliary modules. Certified when used in conjunction with a LUB power base (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider LUFV2 dimensions and weight
Dimensions (L × W × H)
Length
4.7 cm
Width
3.3 cm
Height
9.5 cm
Weight
Net Weight
0.05 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric LUFV2 - TeSys U additional function module to be inserted in advanced power bases LUB120, LUB320, LUB380 for motor load monitoring. It provides a 4-20mA output signal, image of the load ratio, to be connected to a load impedance 100 Ohm typical (500 Ohm max). It measures the phase currents and computes the ratio I average/Ir ratio within the range of 0 to 2 for LUCB and LUCD, and of 0 to 3 for LUCC control units. It requires an external power supply 24V DC. To be inserted in the cavity of a power base provided for the auxiliary modules. Certified when used in conjunction with a LUB power base (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh). We are dedicatedly involved in providing an excellent quality products at Electrihub.
