LRD22 - Thermal Overload Relay, TeSys Deca, 16 to 24 A, class 10A - Schneider Electric

Cat No. LRD22
Category Over Load Relay
Stock In Stock
Condition Brand New, Sealed Packaging
Product Type Over Load Relay
Please contact us for the exact delivery timeline

In Stock — 239 Qty

$51.86
Quantity Expected Delivery
239 Units 25 Business Days

Reach out to us for project inquiries, Add to cart and click on send inquiry

Currently viewed by 11 users
Secure Payment with
Visa, MasterCard, American Express, Apple Pay, Discover, PayPal, Stripe
Need help on Inquiry? Call Us on +1 (888) 293-7436
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach

Technical Documents

No Data Available

There is no data to show you right now.

Technical Specification

Schneider LRD22 Over Load Relay Technical Specification

Over Load Relay
Bimetal relay Type LR-D
Contactor Type LC1D09...LC1D38
Current Range 16-24A
Range of Product TeSys LRD/TeSys Deca
Secondary Volt Ac 400Vac
Sub Family TeSys Deca
Type Thermal Overload Relay

Product Details

Schneider Electric LRD22 Thermal Overload Relay - TeSys LRD overload relays are designed to be used with TeSys D contactors to make a motor starter. This overload relay can be used with 9 amp through 38 amp TeSys D contactors. These differential thermal overload relays detect over currents in the lines to the motor. When an overcurrent is detected the overload relay working with the contactor will disconnect the power to the motor. This will minimize the damage to the motor windings. This overload relay has an adjustable trip current rating of 16 to 24 amperes. This trip current rating is calibrated per Class 10A. Multi standards certified (IEC, UL, CSA, CCC, EAC, ATEX, Marine). We are dedicatedly involved in providing an excellent quality products at Electrihub.

Product Dimensions

Schneider LRD22 dimensions and weight

Dimensions (L × W × H)
Length 4.9 cm
Width 7.2 cm
Height 9 cm
Weight
Net Weight 0.142 kg

Dimensions are approximate. For precise dimensional drawings, contact us.
