LR3D16 - Thermal overload relay, TeSys Deca, 690VAC, 9 to 13A, 1NO+1NC, class 10A, for D12ââ¬Â¦D38 unbalanced loads - Schneider Electric
| Cat No. | LR3D16 |
| Category | Over Load Relay |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | Over Load Relay |
Back Ordered
$52.68
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 41 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider LR3D16 Over Load Relay Technical Specification
| Over Load Relay | |
|---|---|
| Bimetal relay Type | Not Applicable |
| Contactor Type | LC1D |
| Current Range | 9-13A |
| Range of Product | — |
| Secondary Volt Ac | Not Applicable |
| Sub Family | TeSys Deca |
| Type | Thermal Overload Relay |
Product Details
Schneider Electric LR3D16 - TeSys LRD thermal overload relay, 13A/690V, thermal setting range 9-13A, tripping class 10A, for protection of 3-phase motors 5.5kW@400V. Non differential device, it can be used with unbalanced loads. It provides a thermal adjustement dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons, a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing. Connection by screw clamp terminals, it connects directly to the bottom terminals of 3-pole contactors LC1D12-D38. Mounting on DIN rail or screw fixing, separated from the contactor, with use of a terminal block LAD7B106 (to be ordered separately). Multi standards certified (IEC, UL, CSA, CCC, EAC, ATEX, Marine), Green Premium compliant (RoHs/Reach). We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider LR3D16 dimensions and weight
Dimensions (L × W × H)
Length
8.8 cm
Width
7.7 cm
Height
5 cm
Weight
Net Weight
0.141 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
