LR3D146 - TeSys LRD thermal overload relays - 7...10 A - class 10A - Schneider Electric
| Cat No. | LR3D146 |
| Category | Over Load Relay |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | Over Load Relay |
In Stock — 45 Qty
$59.33
| Quantity | Expected Delivery |
|---|---|
| 45 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 44 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider LR3D146 Over Load Relay Technical Specification
| Over Load Relay | |
|---|---|
| Bimetal relay Type | Not Applicable |
| Contactor Type | LC1D |
| Current Range | 7-10A |
| Range of Product | — |
| Secondary Volt Ac | Not Applicable |
| Sub Family | TeSys Deca |
| Type | Thermal Overload Relay |
Product Details
Schneider Electric LR3D146 - TeSys LRD thermal overload relay, 10A/690V, thermal setting range 7-10A, tripping class 10A, for protection of 3-phase motors 4kW@400V. Non differential device, it can be used with unbalanced loads. It provides a thermal adjustement dial, a manual-automatic reset selector, a test selector for simulation of a tripping, reset and stop buttons, a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing. Connection by screw clamp terminals, it connects directly to the bottom terminals of 3-pole contactors LC1D09-D38. Mounting on DIN rail or screw fixing, separated from the contactor, with use of a terminal block LAD7B106 (to be ordered separately). Multi standards certified (IEC, UL, CSA, CCC, EAC, ATEX, Marine), Green Premium compliant (RoHs/Reach). We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider LR3D146 dimensions and weight
Dimensions (L × W × H)
Length
8.8 cm
Width
7.7 cm
Height
5 cm
Weight
Net Weight
0.124 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
