LC2K0610E7 - TeSys K reversing contactor - 3P - AC-3
| Cat No. | LC2K0610E7 |
| Category | Power Contactor |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | Power Contactor |
In Stock — 2 Qty
$108.32
| Quantity | Expected Delivery |
|---|---|
| 2 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 19 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider LC2K0610E7 Power Contactor Technical Specification
| Power Contactor | |
|---|---|
| AC1 Rating | Not Applicable |
| AC3 Rating | 6A |
| Coil Voltage | 48Vac |
| Inbuilt Auxiliary Contact | 1NO |
| Model | K Model |
| No of Pole | 3P |
| Range of Product | — |
Product Details
Schneider Electric LC2K0610E7 - TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 6A/690V AC-3 (2.2kW@400V). It provides 48V 50/60Hz AC coils, 2NO built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider LC2K0610E7 dimensions and weight
Dimensions (L × W × H)
Length
6 cm
Width
9.2 cm
Height
6.5 cm
Weight
Net Weight
0.367 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric LC2K0610E7 - TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 6A/690V AC-3 (2.2kW@400V). It provides 48V 50/60Hz AC coils, 2NO built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh). We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for LC2K0610E7
Every Schneider LC2K0610E7 Power Contactor purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Power Contactor for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Power Contactor for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
Yes, the Schneider LC2K0610E7 power contactor typically supports auxiliary contact blocks which can be used for signaling, interlocking, and control circuit feedback in automation and electrical panels.
The Schneider LC2K0610E7 power contactor is commonly used in motor control circuits, HVAC systems, pump panels, compressors, and industrial automation systems where reliable switching of high-current loads is required.
You can purchase the genuine Schneider LC2K0610E7 power contactor from ElectriHub, a trusted global supplier of electrical switchgear products offering competitive pricing and worldwide delivery.
Yes, the Schneider LC2K0610E7 power contactor is widely used in direct‑on‑line (DOL) starters, star‑delta starters, and other motor control panels where reliable switching is required.
The Schneider LC2K0610E7 power contactor can typically be combined with compatible thermal overload relays to provide protection against motor overload, phase loss, and prolonged current imbalance.
