LC1G400LSEA - High power contactor, TeSys Giga, 3 pole (3NO), AC-3
| Cat No. | LC1G400LSEA |
| Category | Power Contactor |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | Power Contactor |
Back Ordered
$1,462.84
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 28 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider LC1G400LSEA Power Contactor Technical Specification
| Power Contactor | |
|---|---|
| AC1 Rating | 550A |
| AC3 Rating | 400A |
| Coil Voltage | 200-500Vac/dc |
| Inbuilt Auxiliary Contact | - |
| Model | G Model |
| No of Pole | 3P |
| Range of Product | — |
Product Details
Schneider Electric LC1G400LSEA - TeSys Giga high power contactor, 3 poles (3 NO) for category AC-3 applications up to 400A 250kW@440V,It provides a 200-500V AC/DC wide band low consumption electronic coil, PLC output control and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA),Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60°C,It procures high reliability and durability with 5 Mcycles mechanical durability,Local and Remote Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators,It is possibility to replace switching module (main contacts), enhancement contactor life,Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor,To be used with power connection by bolted connection with cable memory kit and control connections by spring terminals, accessible from front for easy and quick replacement,It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106,It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude,The dimension is 290mm x 140mm x 209mm (H x W x D), compact size enables panel space savings,Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach),Unique QR code provides quick access to complete product data. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider LC1G400LSEA dimensions and weight
Dimensions (L × W × H)
Length
37.2 cm
Width
22.5 cm
Height
30.7 cm
Weight
Net Weight
8.99 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric LC1G400LSEA - TeSys Giga high power contactor, 3 poles (3 NO) for category AC-3 applications up to 400A 250kW@440V,It provides a 200-500V AC/DC wide band low consumption electronic coil, PLC output control and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA),Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60°C,It procures high reliability and durability with 5 Mcycles mechanical durability,Local and Remote Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators,It is possibility to replace switching module (main contacts), enhancement contactor life,Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor,To be used with power connection by bolted connection with cable memory kit and control connections by spring terminals, accessible from front for easy and quick replacement,It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106,It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude,The dimension is 290mm x 140mm x 209mm (H x W x D), compact size enables panel space savings,Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach),Unique QR code provides quick access to complete product data. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for LC1G400LSEA
Every Schneider LC1G400LSEA Power Contactor purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Power Contactor for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Power Contactor for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The Schneider LC1G400LSEA contactor allows high‑power circuits to be controlled by a low‑voltage control signal, improving operator safety and enabling automated switching of electrical loads.
You can purchase the genuine Schneider LC1G400LSEA power contactor from ElectriHub, a trusted global supplier of electrical switchgear products offering competitive pricing and worldwide delivery.
The Schneider LC1G400LSEA power contactor can control a wide range of loads including three‑phase motors, heating elements, lighting circuits, compressors, and other industrial electrical equipment.
The coil in the Schneider LC1G400LSEA power contactor energizes the magnetic mechanism that closes the main contacts, allowing the power circuit to energize the connected load.
The Schneider LC1G400LSEA power contactor is typically designed for DIN rail or panel mounting, making it easy to integrate into electrical distribution boards and industrial control panels.
Reviews & Ratings
4.4
5 reviews
5
2
4
3
3
0
2
0
1
0
Just bought LC1G400LSEA for our new project. The build quality exceeds expectations and the electrical performance is exactly as specified.
Ordered LC1G400LSEA and it arrived ahead of time. The build quality is excellent and it's working flawlessly in our system.
Recently purchased LC1G400LSEA and it exceeded my expectations. Robust construction and precise operation. Perfect for our control panel setup.
Got LC1G400LSEA delivered today and it's exactly as advertised. Excellent build quality and reliable electrical performance.
Ordered LC1G400LSEA and it arrived exactly as described. The quality is superb and it's working perfectly for our application.
