CTR TeSysGiga185 4P Std48-130V ACDC S207
| Cat No. | LC1G1854EHES207N |
| Category | Power Contactor |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | Power Contactor |
Back Ordered
$1,260.63
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 10 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider LC1G1854EHES207N Power Contactor Technical Specification
| Power Contactor | |
|---|---|
| AC1 Rating | 185A |
| AC3 Rating | Not Applicable |
| Coil Voltage | 48-130Vac/dc |
| Inbuilt Auxiliary Contact | 1NO+1NC |
| Model | G Model |
| No of Pole | 4P |
| Range of Product | — |
Product Details
Schneider Electric LC1G1854EHES207N - TeSys Giga high power contactor, 4 poles (4 NO) for category AC-1 applications up to 305A @440V. It provides a 48-130V AC/DC wide band low consumption electronic coil and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60°C. It procures high reliability and durability with 5 Mcycles mechanical durability. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It is possibility to replace switching module (main contacts), enhancement contactor life. Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor. To be used with power connection by bolted connection and control connections by spring terminals, accessible from front for easy and quick replacement. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude. The dimension is 255mm x 143mm x 175mm (H x W x D), compact size enables panel space savings. Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach). Unique QR code provides quick access to complete product data. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
No Data Available
There is no data to show you right now.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric LC1G1854EHES207N - TeSys Giga high power contactor, 4 poles (4 NO) for category AC-1 applications up to 305A @440V. It provides a 48-130V AC/DC wide band low consumption electronic coil and embedded highly reliability 1NO+1NC auxiliary contact block (17V 1mA). Designed for demanding applications with maximum operating rates up to 600 cycles per hour and environments until 60°C. It procures high reliability and durability with 5 Mcycles mechanical durability. Local Contact Wear Diagnosis (CWD) as standard function, continuous monitoring with healthy and alarm indicators. It is possibility to replace switching module (main contacts), enhancement contactor life. Contactor can be fixed in all quadrants, maintenance without removing cables/busbars, and OLR could be directly mounted below contactor. To be used with power connection by bolted connection and control connections by spring terminals, accessible from front for easy and quick replacement. It provides IP2x protection in Front face with shrouds conforming to IEC 60529 and VDE 0106. It can cover -25°C to 60°C operation ambient air temperature and directly mounted on plate, No derating up to 3000m altitude. The dimension is 255mm x 143mm x 175mm (H x W x D), compact size enables panel space savings. Multi standards certified(CE,CB,CCC,cULus,EAC,KC,RCM,Marine) and Green Premium compliant (RoHs/Reach). Unique QR code provides quick access to complete product data. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for LC1G1854EHES207N
Every Schneider LC1G1854EHES207N Power Contactor purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Power Contactor for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Power Contactor for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The Schneider LC1G1854EHES207N power contactor can control a wide range of loads including three‑phase motors, heating elements, lighting circuits, compressors, and other industrial electrical equipment.
You can purchase the genuine Schneider LC1G1854EHES207N power contactor from ElectriHub, a trusted global supplier of electrical switchgear products offering competitive pricing and worldwide delivery.
Yes, the Schneider LC1G1854EHES207N power contactor is widely used in direct‑on‑line (DOL) starters, star‑delta starters, and other motor control panels where reliable switching is required.
In automation systems, the Schneider LC1G1854EHES207N power contactor is used to switch motors, pumps, fans, and other electrical loads based on signals from PLCs, timers, or control relays.
The Schneider LC1G1854EHES207N power contactor can typically be combined with compatible thermal overload relays to provide protection against motor overload, phase loss, and prolonged current imbalance.
