LA1KN31
Click to zoom
LA1KN31
Schneider
(No reviews yet)

LA1KN31 - TeSys K - Auxiliary contact block - 3 NO + 1 NC - screw-clamps terminals - Schneider Electric

Cat No. LA1KN31
Category Power Contactor Accessories
Stock In Stock
Condition Brand New, Sealed Packaging
Product Type Power Contactor Accessories

In Stock — 313 Qty

$37.89
Quantity Expected Delivery
313 Units 25 Business Days

Reach out to us for project inquiries, Add to cart and click on send inquiry

Currently viewed by 34 users
Secure Payment with
Visa, MasterCard, American Express, Apple Pay, Discover, PayPal, Stripe
Need help on Inquiry? Call Us on +1 (888) 293-7436
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach

Technical Documents

No Data Available

There is no data to show you right now.

Technical Specification

Schneider LA1KN31 Power Contactor Accessories Technical Specification

Power Contactor Accessories
Contacts —
Other Details 3NO+1NC
Range of Product —
Sub Family Aux. Contact
Type K Model

Product Details

Schneider Electric LA1KN31 - TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K),It provides 3NO+1NC contacts rated up to 10A 690V AC, connection by screw clamp terminals,Front mounting by clip-on, it procures high reliability and durability,Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh). We are dedicatedly involved in providing an excellent quality products at Electrihub.

Product Dimensions

Schneider LA1KN31 dimensions and weight

Dimensions (L × W × H)
Length 3.6 cm
Width 4 cm
Height 3.8 cm
Weight
Net Weight 0.04 kg

Dimensions are approximate. For precise dimensional drawings, contact us.

Related Products

Frequently Bought Together

Product Line Card

No Data Available

There is no data to show you right now.

Alternate Products

Product Overview

Schneider Electric LA1KN31 - TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals (except LP4K, LP5K, CA4K),It provides 3NO+1NC contacts rated up to 10A 690V AC, connection by screw clamp terminals,Front mounting by clip-on, it procures high reliability and durability,Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh). We are dedicatedly involved in providing an excellent quality products at Electrihub.

Frequently Asked Questions for LA1KN31

Every Schneider LA1KN31 Power Contactor Accessories purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence._x000D_
_x000D_
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Power Contactor Accessories for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety._x000D_
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The Schneider LA1KN31 is an auxiliary contact block designed to provide additional signaling and control logic for power contactors. In Indian industrial automation, it is commonly used for electrical interlocking, remote status indication (ON/OFF), and PLC feedback to ensure safe motor operation.
The LA1KN31 model is specifically designed for a particular range. For instance, LA1K series are for TeSys K (compact) contactors, while LADN/LAD8 series are for TeSys D/Deca contactors. It is essential to verify the frame size to ensure a secure mechanical snap-on fit within your control panel.
The LA1KN31 features high-reliability contacts rated for standard industrial control voltages used in India, such as 110V, 230V, or 415V AC. It is engineered to handle low-level switching currents (typically up to 10A thermal current) with high mechanical durability exceeding millions of cycles.
By adding the LA1KN31 to your power contactor, you can implement safety interlocks that prevent simultaneous operation of conflicting loads. Its finger-safe (IP20) terminal design complies with international safety standards, protecting maintenance personnel in Indian factories from accidental contact with live parts.
The LA1KN31 features a modular, tool-free 'clip-on' mounting mechanism. It can be easily mounted on the front or side of the compatible contactor. In the Indian context, this modularity allows for quick field upgrades and reduces downtime during panel maintenance or logic modification.
The Schneider LA1KN31 features a conventional thermal current (I_{th}) of 10A at \le 50^\circ C, adhering to IEC 60947-5-1. This ensures high-performance signaling in compact TeSys K control circuits used in Indian panel boards.
The LA1KN31 is rated for AC-15 (600V AC) and DC-13 (600V DC) utilization categories. It provides reliable switching for control coils and signaling lamps across a wide operational voltage range from 17V to 690V AC/DC.
Equipped with high-conductivity contacts, the LA1KN31 has a minimum switching current of 5mA and a minimum switching voltage of 17V. This technical specification prevents signal loss when interfaced with modern PLCs and electronic controllers.
The LA1KN31 auxiliary block is designed for heavy-duty industrial use, offering a mechanical durability of 5 million cycles. This ensures long-term maintenance-free operation in demanding Indian manufacturing environments.
The LA1KN31 uses screw clamp terminals designed for a tightening torque of 0.8 N.m to 1.3 N.m. It accommodates flexible cables up to 1.5mm^2 or rigid cables up to 4mm^2, ensuring secure electrical terminations.
