LA1KN11
Click to zoom
LA1KN11
Schneider
(No reviews yet)

LA1KN11 - TeSys K - Auxiliary contact block - 1 NO + 1 NC - screw-clamps terminals - Schneider Electric

Cat No. LA1KN11
Category Power Contactor Accessories
Stock In Stock
Condition Brand New, Sealed Packaging
Product Type Power Contactor Accessories

In Stock — 1465 Qty

$22.53
Quantity Expected Delivery
1,465 Units 25 Business Days

Reach out to us for project inquiries, Add to cart and click on send inquiry

Currently viewed by 44 users
Secure Payment with
Visa, MasterCard, American Express, Apple Pay, Discover, PayPal, Stripe
Need help on Inquiry? Call Us on +1 (888) 293-7436
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach

Technical Documents

No Data Available

There is no data to show you right now.

Technical Specification

Schneider LA1KN11 Power Contactor Accessories Technical Specification

Power Contactor Accessories
Contacts —
Other Details 1NO+1NC
Range of Product —
Sub Family Aux. Contact
Type K Model

Product Details

Schneider Electric LA1KN11 - TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals,It provides 1NO+1NC contacts rated up to 10A 690V AC, connection by screw clamp terminals,Front mounting by clip-on, it procures high reliability and durability,Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh). We are dedicatedly involved in providing an excellent quality products at Electrihub.

Product Dimensions

Schneider LA1KN11 dimensions and weight

Dimensions (L × W × H)
Length 4 cm
Width 4 cm
Height 3.7 cm
Weight
Net Weight 0.033 kg

Dimensions are approximate. For precise dimensional drawings, contact us.

Related Products

Frequently Bought Together

Product Line Card

No Data Available

There is no data to show you right now.

Alternate Products

Product Overview

Schneider Electric LA1KN11 - TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K, CA.K with screw clamp terminals,It provides 1NO+1NC contacts rated up to 10A 690V AC, connection by screw clamp terminals,Front mounting by clip-on, it procures high reliability and durability,Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh). We are dedicatedly involved in providing an excellent quality products at Electrihub.

Frequently Asked Questions for LA1KN11

Every Schneider LA1KN11 Power Contactor Accessories purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.

Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Power Contactor Accessories for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The Schneider LA1KN11 is an auxiliary contact block designed to provide additional signaling and control logic for power contactors. In Indian industrial automation, it is commonly used for electrical interlocking, remote status indication (ON/OFF), and PLC feedback to ensure safe motor operation.
The LA1KN11 model is specifically designed for a particular range. For instance, LA1K series are for TeSys K (compact) contactors, while LADN/LAD8 series are for TeSys D/Deca contactors. It is essential to verify the frame size to ensure a secure mechanical snap-on fit within your control panel.
The LA1KN11 features high-reliability contacts rated for standard industrial control voltages used in India, such as 110V, 230V, or 415V AC. It is engineered to handle low-level switching currents (typically up to 10A thermal current) with high mechanical durability exceeding millions of cycles.
By adding the LA1KN11 to your power contactor, you can implement safety interlocks that prevent simultaneous operation of conflicting loads. Its finger-safe (IP20) terminal design complies with international safety standards, protecting maintenance personnel in Indian factories from accidental contact with live parts.
The LA1KN11 features a modular, tool-free 'clip-on' mounting mechanism. It can be easily mounted on the front or side of the compatible contactor. In the Indian context, this modularity allows for quick field upgrades and reduces downtime during panel maintenance or logic modification.
The Schneider LA1KN11 features a conventional thermal current (I_{th}) of 10A at \le 50^\circ C, adhering to IEC 60947-5-1. This ensures high-performance signaling in compact TeSys K control circuits used in Indian panel boards.
The LA1KN11 is rated for AC-15 (600V AC) and DC-13 (600V DC) utilization categories. It provides reliable switching for control coils and signaling lamps across a wide operational voltage range from 17V to 690V AC/DC.
Equipped with high-conductivity contacts, the LA1KN11 has a minimum switching current of 5mA and a minimum switching voltage of 17V. This technical specification prevents signal loss when interfaced with modern PLCs and electronic controllers.
The LA1KN11 auxiliary block is designed for heavy-duty industrial use, offering a mechanical durability of 5 million cycles. This ensures long-term maintenance-free operation in demanding Indian manufacturing environments.
The LA1KN11 uses screw clamp terminals designed for a tightening torque of 0.8 N.m to 1.3 N.m. It accommodates flexible cables up to 1.5mm^2 or rigid cables up to 4mm^2, ensuring secure electrical terminations.

Reviews & Ratings

4.8
8 reviews
5
6
4
2
3
0
2
0
1
0
Leonardo DiCaprio Apr 28, 2026

The LA1KN11 is an essential component for our machine-level control circuits. Maintains excellent electrical characteristics and stability even under continuous high-duty cycles. Working flawlessly in our modular power distribution unit since the integration. Exceptional service and genuine products from the Electrihub team throughout. Overall, a very satisfying purchase experience for our engineering department.

Julian Vance Apr 28, 2026

Specifically selected the Schneider LA1KN11 for a high-specification distribution board upgrade. The contact response and trip accuracy are perfectly calibrated for precision engineering. A great addition to our inventory of critical spares for this infrastructure project. Electrihub provided full technical documentation and traceability for this order. Perfect balance of technical excellence and competitive global pricing.

Helen Mirren Apr 28, 2026

Procured the LA1KN11 for a high-specification industrial control system. Thermal dissipation is impressive, which is critical for our high-density panel boards. Ideal for the automation and circuit protection logic we are currently managing. Trustworthy procurement process; Electrihub is our top-tier supplier for electrical spares. Highly recommended for professional machine-building and electrical applications.

George Clooney Apr 28, 2026

Integrating the Schneider LA1KN11 into our facility's power management system was very efficient. Verified the dielectric strength and insulation resistance; everything is within tolerance. Fits perfectly into our control panel with zero alignment or mounting issues. Ordering from Electrihub ensures we get original equipment without any logistics delay. A dependable choice for ensuring long-term system reliability and uptime.

Harrison Ford Apr 28, 2026

The build quality of this Schneider Power Contactor Accessories is exceptional for industrial-grade applications. The modular design and standard mounting interface made the installation very straightforward. Handled the heavy-duty cycles of our industrial setup without any performance drift. The logistics support from Electrihub was top-notch, helping us meet our deadline. Will definitely continue to source our Schneider components from Electrihub.

Sandip Patil Apr 28, 2026

Selected the LA1KN11 for its compatibility with our existing Schneider infrastructure. Housing insulation and dielectric strength meet all standard safety certifications. Fits seamlessly into our modular power distribution unit with zero space waste. Grateful to RAS Electrihub for the secure packaging and prompt dispatch. Overall, a top-quality purchase for our industrial automation requirements.

Manoj Singh Apr 28, 2026

The Schneider LA1KN11 was the specific technical choice for our automation rack. Standard DIN-rail mounting and clear labeling made the wiring process very efficient. Functions flawlessly within our motor control center (MCC) logic setup. Very impressed with the authentic Schneider supply from the RAS Electrihub team. An essential spare for maintaining operational continuity in our facility.

Vivek Pandey Apr 28, 2026

Integrating the LA1KN11 was a priority for our latest control panel upgrade. Auxiliary contacts provide consistent logic feedback to our remote PLC monitoring. Provides reliable and precise protection for our sensitive automation circuits. Buying from RAS Electrihub gives us confidence in product traceability. Satisfies all our internal technical audit requirements for switchgear.
