EGB26035 - Mini circuit breaker, E-Frame, 35A, 2 pole, 600Y/347VAC, 65kA max, bolt on [TAA] - Schneider Electric
| Cat No. | EGB26035 |
| Category | MCB |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MCB |
Back Ordered
$237.22
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 42 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider EGB26035 MCB Technical Specification
| MCB | |
|---|---|
| Breaking Cap | 65kA |
| Curve | Not Applicable |
| Model | EGB |
| No of pole | 2P |
| Range of Product | — |
| Rating | 35A |
Product Details
Schneider Electric EGB26035 - E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 35A, 2 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 65 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider EGB26035 dimensions and weight
Dimensions (L × W × H)
Length
24.89 cm
Width
15.24 cm
Height
9.4 cm
Weight
Net Weight
1.145 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
