ATV340U75N4 - variable speed drive, Altivar Machine ATV340, 7.5kW, heavy duty, 400V, 3 phases - Schneider Electric

Schneider Electric ATV340U75N4 - This Altivar 340 variable speed drive can feed 3-phase synchronous and asynchronous motors in open and closed loop control,Altivar Machine ATV340 drives are sized heavy duty as standard,It works at a rated power up to 7.5kW / 10hp and a rated voltage from 380V to 480V AC,ATV340 has been designed to meet the needs of applications for harsh environments, such as vibration, shock and non-conductive dust and where high temperature resistance up to 60 °C is needed,This product integrates Modbus serial line communication protocols as standard,it weighs 3kg and its dimensions are, 110mm wide, 270mm high, 234mm deep,ATV340 incorporates functions and features suitable for the most common applications, including packaging, material handling, material working, hoisting,It conforms to international standards IEC/EN 61800-5-1 and IEC/EN 61800-3 (immunity and conducted and radiated EMC emissions), IEC 60721-3, IEC 61508, IEC 13849-1. It is also CE, UL, CSA, and TÃV certified,Accessories and options (encoder interface modules, I/O expansion modules, communication modules, braking resistors, line chokes, additional EMC filters) are available with Altivar Machine ATV340 drives, depending on the drive rating,It is designed to be mounted in vertical position (+/- 10 °) on a panel, thanks to 4 fixing holes,It is fully integrated inside Schneider Electricâs EcoStruxure Machine through DTM. It is possible to configure, control, and diagnose ATV340 drives directly in SoMachine and SoMove software by means of the same software brick (DTM),It is eco-friendly and complies with directives such as RoHS relating to environmental protection. We are dedicatedly involved in providing an excellent quality products at Electrihub.
