ATV320U22M2C412 - Variable speed drive, Altivar Solar, 2.2kW, 200 to 240V, 1 phase, compact - Schneider Electric
| Cat No. | ATV320U22M2C412 |
| Category | VFD |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | VFD |
In Stock — 6 Qty
$435.01
| Quantity | Expected Delivery |
|---|---|
| 6 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 12 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider ATV320U22M2C412 VFD Technical Specification
| VFD | |
|---|---|
| IP Protection | Not Applicable |
| kW Rating | 2.2 kW |
| Range of Product | Altivar |
| Series | ATV320 |
| Type | Altivar |
Product Details
Schneider Electric ATV320U22M2C412 - Altivar Solar variable speed drive range is designed to improve pump performance and increase pump availability while reducing the total system cost. They are robust, simple to commission, and easily integrated into different machine layouts and cabinets. It controls motors of 2.2kW/3HP power rating with a single-phase supply voltage of 200¢Â¦240V 50/60Hz. It embeds dedicated functions for synchronous motors, ATV logic, and pumping and safety functions. Altivar Solar VSD integrates the Modbus and CANopen communication protocols as standard. The Altivar Solar VFDs have a compact control block design. Its dimensions are 105mm (width) x 142mm (depth) x 158mm (height) and it weighs 1.6kg. Altivar Solar drives bring key benefits to our solar pump system builders. It conforms to IEC/EN/UL 61800-5-1, EN/IEC 61800-3 (Environments 1 and 2, category C2, C3), IEC 60721-3, IEC 61508, and IEC 13849-1. It is certified CE, UKCA, UR (UL recognized component), UL 61800-5-1, RCM, and RoHS EU and China. These drives have a dedicated compatibility mode function, enabling customers to replace a legacy product ATV312 Solar without changing the PLC program. Our Altivar Solar Sizer tool will help you design your Solar system. The Altivar Solar range achieves superior upgradable performance by enhancing its embedded functionality and performance capacity for hardware and software. It is a Green Premium product designed to take environmental considerations beyond current directives and regulations and complies with RoHS and REACH. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider ATV320U22M2C412 dimensions and weight
Dimensions (L × W × H)
Length
18.5 cm
Width
18.5 cm
Height
18 cm
Weight
Net Weight
1.899 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric ATV320U22M2C412 - Altivar Solar variable speed drive range is designed to improve pump performance and increase pump availability while reducing the total system cost. They are robust, simple to commission, and easily integrated into different machine layouts and cabinets. It controls motors of 2.2kW/3HP power rating with a single-phase supply voltage of 200¢Â¦240V 50/60Hz. It embeds dedicated functions for synchronous motors, ATV logic, and pumping and safety functions. Altivar Solar VSD integrates the Modbus and CANopen communication protocols as standard. The Altivar Solar VFDs have a compact control block design. Its dimensions are 105mm (width) x 142mm (depth) x 158mm (height) and it weighs 1.6kg. Altivar Solar drives bring key benefits to our solar pump system builders. It conforms to IEC/EN/UL 61800-5-1, EN/IEC 61800-3 (Environments 1 and 2, category C2, C3), IEC 60721-3, IEC 61508, and IEC 13849-1. It is certified CE, UKCA, UR (UL recognized component), UL 61800-5-1, RCM, and RoHS EU and China. These drives have a dedicated compatibility mode function, enabling customers to replace a legacy product ATV312 Solar without changing the PLC program. Our Altivar Solar Sizer tool will help you design your Solar system. The Altivar Solar range achieves superior upgradable performance by enhancing its embedded functionality and performance capacity for hardware and software. It is a Green Premium product designed to take environmental considerations beyond current directives and regulations and complies with RoHS and REACH. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for ATV320U22M2C412
Every Schneider ATV320U22M2C412 VFD purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right VFD for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right VFD for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The Schneider ATV320U22M2C412 (Altivar Machine ATV320 (Compact)) has a power rating of 2.2 kW (3 HP) and is engineered for 1-Phase 200V to 240V AC (50/60 Hz), making it fully compatible with Indian 3-phase 415V AC / single-phase 230V AC 50 Hz power supply standards. It delivers a rated output current of 11.0 A with heavy-duty thermal overload capacity. Buy 100% genuine Schneider variable frequency drives with official manufacturer warranty at Electrihub India (electrihub.in).
The Schneider ATV320U22M2C412 variable frequency drive supports sensorless vector control (SVC), V/F (volts-per-hertz) scalar control, and energy-saving quadratic torque profiles. It is widely deployed across Indian industries including centrifugal pumps, HVAC fans, conveyor systems, textile machinery, plastic extruders, packaging lines, and CNC auxiliary spindles. Order online from Electrihub India with prompt dispatch across Noida, Delhi NCR, Mumbai, Ahmedabad, Bengaluru, Chennai, and PAN India.
The Schneider ATV320U22M2C412 VFD comes equipped with standard industrial communication including RS-485 Modbus RTU / ASCII (with select models supporting Ethernet/IP, CANopen, or Profinet expansion cards). It features multi-function programmable digital inputs, analog inputs (0-10V DC / 4-20mA), relay alarm outputs, and analog monitoring outputs for seamless PLC and SCADA integration in Indian automation panels. Available on electrihub.in.
Engineered for demanding Indian manufacturing environments, the Schneider ATV320U22M2C412 features an enclosure rating of IP20 with conformal coated printed circuit boards (3C3/3S2 compliance) to resist humidity, chemical vapors, and dust. Built-in electrical protections include motor overload (Class 10/20), phase loss, overvoltage, undervoltage, output short-circuit, ground fault, and overtemperature cutoff, operating reliably up to 50°C ambient temperature. Verified technical support available at Electrihub India.
Electrihub India is an authorized e-commerce distributor offering 100% genuine Schneider industrial switchgear and automation products. When ordering the ATV320U22M2C412 from electrihub.in, you receive GST-compliant tax invoices, full manufacturer warranty, factory-sealed packaging, technical datasheet support, competitive wholesale pricing, and express pan-India logistics delivery.
The Schneider ATV320U22M2C412 (Altivar Machine ATV320 (Compact Book/Compact Format)) is engineered for global industrial power grids, featuring an input voltage rating of 1-Phase 200-240V AC, 50/60Hz with operating frequency flexibility of 50/60 Hz (±5%). It delivers a nominal power output of 2.2 kW (3.0 HP) and a continuous rated current of 11.0 A. Designed to meet stringent international standards including CE, UL, cUL, and RoHS, the drive handles standard industrial overload duties (150% rated current for 60 seconds in Heavy Duty applications and 110-120% in Normal Duty applications), ensuring dependable continuous operation across worldwide manufacturing plants. Electrihub provides global shipping and technical compliance verification for this model.
The Schneider ATV320U22M2C412 incorporates advanced motor control modes including Sensorless Flux Vector Control (SFVC), V/F (2-point, 5-point, Energy Saving), Synchronous Motor Control. It provides superior dynamic speed control, high starting torque (up to 150-200% at low frequencies), and automatic slip compensation. It supports stationary and rotational auto-tuning to match motor equivalent circuit parameters accurately. Dynamic deceleration is supported via its Embedded STO (SIL3 / PL e) plus 4 additional safety functions: SS1, SLS, SMS, GDL, enabling connection of external dynamic braking resistors for rapid deceleration in high-inertia loads and cyclic stopping regimes.
Designed for seamless automation architecture integration, the Schneider ATV320U22M2C412 provides robust connectivity options: Embedded Modbus RTU & CANopen, Optional Ethernet/IP, PROFINET, EtherCAT, Modbus TCP, DeviceNet. It features multi-channel programmable digital inputs, analog inputs (0-10V / 4-20mA), relay alarm outputs, and analog monitoring outputs. For plant and machine safety compliance, it incorporates Embedded STO (SIL3 / PL e) plus 4 additional safety functions: SS1, SLS, SMS, GDL, reducing peripheral safety hardware requirements while complying with international machinery safety directives (IEC/EN 61800-5-2 / ISO 13849-1).
The Schneider ATV320U22M2C412 comes in a robust IP20 (Compact Format / Book Format) enclosure format, suitable for clean cabinet installations or modular panel layouts. It operates reliably across ambient temperature ranges from -10°C up to +50°C (derating up to +60°C depending on carrier frequency and enclosure ventilation). To ensure high reliability in aggressive industrial atmospheres (dust, moisture, chemical vapors), internal PCBs are treated with protective conformal coating (IEC 60721-3-3 standards). Built-in or optional EMC filter options suppress radio frequency interference (RFI) to satisfy global EN 61800-3 Category C1/C2/C3 standards.
The Schneider ATV320U22M2C412 is optimized for: Industry-standard machine drive with embedded ATVLogic (mini-PLC functionality) for packaging, material handling, hoisting, and textile machinery.. When selecting and sizing this unit, engineers should evaluate peak full-load amps (FLA), duty cycle, ambient thermal margins, and braking resistor requirements. Sourcing the Schneider ATV320U22M2C412 from Electrihub guarantees 100% factory-original industrial automation equipment with verified global warranty, authentic manufacturer serial numbers, competitive enterprise pricing, and fast international freight logistics to industrial sites worldwide.
