A9V41425 - Vigi iC60 - earth leakage add-on block - 4P - 25A - 30mA - AC type - Schneider Electric
| Cat No. | A9V41425 |
| Category | RCCB/ELCB |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
Back Ordered
$190.75
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 47 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
No Data Available
There is no data to show you right now.
Product Details
Schneider A9V41425 - This Acti9 Vigi iC60 is a modular add-on residual current devices. It is a 4P, rated current is 25A, operating voltage is 400VAC to 415VAC according to IEC 61009-1. The earth leakage protection class is AC type with a sensitivity of 30mA and a voltage independent technology. This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards. A VisiTrip window is here to indicate a fault tripping by a red mechanical indicator on the front face. It can be combined with iC60 or Acti9 Reflex iC60, to provide protection of persons and protection of installations. This product is compliant with EN 61009-1 and IEC 61009-1 standard. The Ue rated operational voltage is 400VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 6kV. The pollution degree is 3. It can be mounted on DIN rail. The width in 9mm pitches is 6. The dimensions are (W) 54mm x (H) 91mm x (D) 73.5mm. The weight is 0.245kg. The degree of protection is IP20 and IP40 in an enclosure. The operating temperature -5°C to +60°C. The storage temperature is -40°C to +85°C.Specifications We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9V41425 dimensions and weight
Dimensions (L × W × H)
Length
14.6 cm
Width
12.2 cm
Height
8.7 cm
Weight
Net Weight
0.218 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
