A9N19663 - Acti 9 - earth leakage circuit breaker - DPN N Vigi - 1P + N - 10A - 30mA - Schneider Electric
| Cat No. | A9N19663 |
| Category | RCBO Breaker |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | RCBO Breaker |
In Stock — 204 Qty
$73.62
| Quantity | Expected Delivery |
|---|---|
| 204 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 13 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9N19663 RCBO Breaker Technical Specification
| RCBO Breaker | |
|---|---|
| Breaking Cap | 6kA |
| Curve | C |
| No of pole | 1P+N |
| Others | Acti9 |
| Rating | 10A |
| Rating SensitivitymA | 30mA |
| Type | AC |
Product Details
Schneider Electric A9N19663 - This Acti9 DPN N Vigi is an earth leakage circuit breaker,It is a 1P+N circuit breaker and rated current is 10A,The earth leakage protection class is AC type with a sensitivity of 30mA and a voltage independent technology,This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards,The DPN Vigi residual current device provides complete protection for ï¬nal circuits against overcurrents and insulation faults,This product provides complete protection for people against electric shocks by direct contacts (30 mA),,This product is compliant with EN 61009-1 and IEC 61009-1 standard,Electrical endurance goes up to 20000 cycles. Mechanical endurance goes up to 20000 cycles,The Ui rated insulation voltage is 400VAC. The Uimp rated impulse withstand voltage is 4kV,The pollution degree is 3,It can be mounted on DIN rail. The width in 9mm pitches is 4,The product color is white (RAL9003). The weight is 0.19kg,The degree of protection is IP20 and IP40 in an enclosure,The operating temperature -5°C to +60°C. The storage temperature is -40°C to +85°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9N19663 dimensions and weight
Dimensions (L × W × H)
Length
10 cm
Width
4 cm
Height
8.5 cm
Weight
Net Weight
0.186 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
No Data Available
There is no data to show you right now.
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric A9N19663 - This Acti9 DPN N Vigi is an earth leakage circuit breaker,It is a 1P+N circuit breaker and rated current is 10A,The earth leakage protection class is AC type with a sensitivity of 30mA and a voltage independent technology,This product protects against short circuit, cable overload, electrical shock by indirect contact and fire hazards,The DPN Vigi residual current device provides complete protection for ï¬nal circuits against overcurrents and insulation faults,This product provides complete protection for people against electric shocks by direct contacts (30 mA),,This product is compliant with EN 61009-1 and IEC 61009-1 standard,Electrical endurance goes up to 20000 cycles. Mechanical endurance goes up to 20000 cycles,The Ui rated insulation voltage is 400VAC. The Uimp rated impulse withstand voltage is 4kV,The pollution degree is 3,It can be mounted on DIN rail. The width in 9mm pitches is 4,The product color is white (RAL9003). The weight is 0.19kg,The degree of protection is IP20 and IP40 in an enclosure,The operating temperature -5°C to +60°C. The storage temperature is -40°C to +85°C. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for A9N19663
Every Schneider A9N19663 RCBO Breaker purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging — ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right RCBO Breaker for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right RCBO Breaker for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The Schneider A9N19663 RCBO (Residual Current Breaker with Overcurrent protection) combines the features of an MCB and an RCCB into a single compact device. It saves significant panel board space while offering dual protection: short-circuit/overload protection for wiring and earth-leakage/shock protection for humans.
The Schneider A9N19663 RCBO is engineered to deliver standard industrial-grade short-circuit breaking capacities (typically 6kA or 10kA). It offers individual circuit isolation, meaning an earth fault or overload on one branch will only trip the specific A9N19663 RCBO rather than cutting off power to the entire panel board.
Yes, the Schneider A9N19663 RCBO is ideal for dedicated loads where continuity of service is crucial. It minimizes nuisance tripping while providing precise overcurrent and earth fault protection for sensitive electronic devices, medical equipment, or heavy domestic appliances.
The Schneider A9N19663 RCBO fully conforms to global IEC/EN 61009-1 standards and corresponding Indian electrical codes. It is fine-tuned to function reliably under extreme ambient temperatures and fluctuating grid voltages common in industrial regions in India.
To ensure you are getting an authentic product, purchase the Schneider A9N19663 via RAS Electrihub. Electrihub sources products directly from official distributors, ensuring brand-new switchgear complete with batch numbers, official manufacturer warranties, and dynamic online technical assistance.
The Schneider Electric A9N19663 RCBO (Residual Current Breaker with Overcurrent Protection) sourced from Electrihub combines short-circuit/overload protection (MCB functionality) and earth leakage protection (RCCB functionality) in a single integrated housing. This optimizes distribution board space and prevents nuisance tripping across electrical circuits.
The Schneider A9N19663 typically incorporates a Type C or Type B instantaneous tripping curve suited for commercial or general inductive loads, featuring a robust short-circuit breaking capacity rated under international standards (such as IEC 61009-1). For detailed datasheet specifications on this exact model, contact the technical support team at Electrihub.
The A9N19663 is engineered for precise space-saving configurations. Depending on its specific pole architecture (e.g., 1P+N or 2P), it fits standard global voltage standards. Electrihub distributes this globally with guaranteed performance across matching frequencies (50/60 Hz).
By isolating only the specific faulty branch or sub-circuit rather than shutting down the entire distribution section, the Schneider A9N19663 RCBO limits operational downtime. This makes it an ideal option for modern datacenters, critical industrial machinery, and premium commercial infrastructure managed via Electrihub.
Electrihub offers comprehensive online product pages where you can request architectural specifications, terminal torque parameters, and standard technical documentation for the Schneider Electric A9N19663 RCBO Breaker.
