A9L15693 - iPF K 20 modular surge arrester - 3 poles + N - 340V - Schneider Electric
| Cat No. | A9L15693 |
| Category | Surge Protection Device |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | Surge Protection Device |
In Stock — 36 Qty
$236.27
| Quantity | Expected Delivery |
|---|---|
| 36 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 25 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider A9L15693 Surge Protection Device Technical Specification
| Surge Protection Device | |
|---|---|
| Discharge Capacity | 20kA |
| Family | A9L |
| Poles | 1P+N |
| Type | Type 2 |
| Voltage Rating | 340Vac |
Product Details
Schneider Electric A9L15693 - This Acti9 iPF K 20 product is a modular surge arrester. It protects 3P+N installations. The Imax maximum discharge current is 20kA .The In nominal discharge current is 5kA. The multi-pole single-piece surge arrester range is adapted for TT, TN-S, TN-C earthing systems. This type 2 incoming protection surge arrester is recommended for a medium risk level. The Uc maximum continuous operating voltage in common mode is 260VAC between neutral and earth, and is 340VAC between phase and earth. The Uc maximum continuous operating voltage in differential mode (between phase and neutral) is 340VAC. The Up Voltage protection level is 1.5kV in common mode (between neutral and earth) and is 1.1kV in differential mode (between phase and neutral). The Ue rated operational voltage is 230VAC or 400VAC +/- 10%. The product colour is white (RAL9003).The dimensions are (W) 72mm x (H) 81mm x (D) 69mm. The weight is 420g. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 85°C. This product is compliant with IEC 61643-11 and EN 61643-11 standards. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider A9L15693 dimensions and weight
Dimensions (L × W × H)
Length
8.1 cm
Width
8 cm
Height
7 cm
Weight
Net Weight
0.372 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
No Data Available
There is no data to show you right now.
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric A9L15693 - This Acti9 iPF K 20 product is a modular surge arrester. It protects 3P+N installations. The Imax maximum discharge current is 20kA .The In nominal discharge current is 5kA. The multi-pole single-piece surge arrester range is adapted for TT, TN-S, TN-C earthing systems. This type 2 incoming protection surge arrester is recommended for a medium risk level. The Uc maximum continuous operating voltage in common mode is 260VAC between neutral and earth, and is 340VAC between phase and earth. The Uc maximum continuous operating voltage in differential mode (between phase and neutral) is 340VAC. The Up Voltage protection level is 1.5kV in common mode (between neutral and earth) and is 1.1kV in differential mode (between phase and neutral). The Ue rated operational voltage is 230VAC or 400VAC +/- 10%. The product colour is white (RAL9003).The dimensions are (W) 72mm x (H) 81mm x (D) 69mm. The weight is 420g. The degree of protection is IP20 and IP40 in modular enclosure. The operating temperature is -25°C to 60°C. The storage temperature is -40°C to 85°C. This product is compliant with IEC 61643-11 and EN 61643-11 standards. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for A9L15693
The Schneider Surge Protection Device A9L15693 is engineered to safeguard electrical installations and equipment from transient overvoltages. It ensures reliable protection against lightning strikes and switching surges. A9L15693 offers modular design, thermal disconnection, and visual indicators for status monitoring.
The Schneider Surge Protection Device A9L15693 functions by diverting surge energy safely to the ground, thereby limiting the overvoltage reaching sensitive equipment. It contains MOV and GDT components that absorb high energy surges, ensuring continuous system uptime and safety compliance.
The Schneider Surge Protection Device A9L15693 can be installed in main electrical panels, sub-distribution boards, or directly at equipment inlets. It is suitable for residential, commercial, and industrial applications that require Class I, Class II, or Class III surge protection.
The Schneider Surge Protection Device A9L15693 is available in various voltage and current discharge ratings. It supports single-phase and three-phase systems, with nominal discharge current (In) and maximum discharge current (Imax) options that comply with IEC 61643 standards.
The Schneider Surge Protection Device A9L15693 includes a visual status indicator and optional remote signaling contact for maintenance alerts. It is designed for easy module replacement and long operational life. Regular inspection ensures optimal surge protection and safety performance.
The price of Schneider Surge Protection Device A9L15693 depends on its type (Type 1, Type 2, or Type 3), discharge capacity, and voltage class. For the latest and most competitive pricing of A9L15693, visit Electrihub Surge Protection Device section to get verified Schneider products with warranty.
The technical data sheet for Schneider Surge Protection Device A9L15693 provides detailed specifications, including voltage rating, discharge current, protection level, and installation guidelines. You can download the official datasheet for A9L15693 directly from the Electrihub Surge Protection Device product page.
Every Schneider A9L15693 Surge Protection Device purchased from Electrihub is 100% genuine, brand new, and supplied in original sealed packaging ensuring top performance and reliability. We source all products from trusted Schneider supply channels, so you can buy with complete confidence.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Surge Protection Device for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Electrihub offers competitive pricing, fast delivery, and expert support to help you select the right Surge Protection Device for your application. Whether for industrial automation, electrical panels, or control systems, you can rely on Electrihub for authentic Schneider products that deliver consistent quality and safety.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The price of Schneider A9L15693 Surge Protection Device depends on specifications, availability, and market conditions. You can check the latest GST-inclusive price on Electrihub India, which provides genuine products, transparent billing, and PAN India delivery.
