56508 - residual current protection relay, Vigirex RH197P, 30 mA to 30 A, 380/415 VAC 50/60Hz, alarm 50%, front panel mounting - Schneider Electric
| Cat No. | 56508 |
| Category | Over Load Relay |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | Over Load Relay |
Back Ordered
$1,829.61
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 10 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider 56508 Over Load Relay Technical Specification
| Over Load Relay | |
|---|---|
| Bimetal relay Type | - |
| Contactor Type | - |
| Current Range | - |
| Range of Product | — |
| Secondary Volt Ac | 380/415Vac |
| Sub Family | Vigirex Relays |
| Type | Earth Leakage Protection Relay |
Product Details
Schneider Electric 56508 - VigiPacT RH197P is a front panel mounting residual current protection relay. It protects against people direct or indirect contact, property fire hazards and motors. It measures the earth leakage current in an electrical installation via its associated toroid. It trips the associated circuit breaker when the set residual operation current is overrun. The operational supply voltage is 380/415VAC 50/60Hz. It is a type A earth-leakage protection class. The current sensitivity is selectable with 19 thresholds from 30 mA to 30 A. The time delay is selectable with 7 settings from instantaneous to 4.5s. The alarm is set by Dip switch at 50% of IDn. A switch make the selection between local manual reset or automatic reset after a fault clearance. The monitored distribution system voltage is up to 1000 VAC 50/60/400 Hz. It is installed on a front panel switchboard and the protection degree is IP40. It must be associated with a compatible Schneider Electric type A toroid or rectangular sensor. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider 56508 dimensions and weight
Dimensions (L × W × H)
Length
10 cm
Width
8 cm
Height
8.5 cm
Weight
Net Weight
0.334 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
No Data Available
There is no data to show you right now.
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
Schneider Electric 56508 - VigiPacT RH197P is a front panel mounting residual current protection relay. It protects against people direct or indirect contact, property fire hazards and motors. It measures the earth leakage current in an electrical installation via its associated toroid. It trips the associated circuit breaker when the set residual operation current is overrun. The operational supply voltage is 380/415VAC 50/60Hz. It is a type A earth-leakage protection class. The current sensitivity is selectable with 19 thresholds from 30 mA to 30 A. The time delay is selectable with 7 settings from instantaneous to 4.5s. The alarm is set by Dip switch at 50% of IDn. A switch make the selection between local manual reset or automatic reset after a fault clearance. The monitored distribution system voltage is up to 1000 VAC 50/60/400 Hz. It is installed on a front panel switchboard and the protection degree is IP40. It must be associated with a compatible Schneider Electric type A toroid or rectangular sensor. We are dedicatedly involved in providing an excellent quality products at Electrihub.
