3104140042 - NEMA Motor Starter, Type S, replacement coil, 110/120VAC 50/60Hz, NEMA Size 00, 0 and 1 starters and 8903SM lighting - Schneider Electric
| Cat No. | 3104140042 |
| Category | MPCB Accessories |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MPCB Accessories |
Back Ordered
$256.61
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 42 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
Schneider 3104140042 MPCB Accessories Technical Specification
| MPCB Accessories | |
|---|---|
| Other Details | 110/120Vac |
| Range of Product | — |
| Sub Family | Magnetic Coil |
| Type | NEMA |
Product Details
Schneider Electric 3104140042 - The coil can be easily replaced in Type S contactors or starters. By changing out the coil, the contactor or starter can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor or starter if the coil were to fail. This coil is used in an 8502SA, series A, 8502SB, or 8502SC contactor, in an 8536SA, series A, 8536SB, or 8536SC starter or an 8903SM lighting contactor. The coil is rated for 110/120 VAC 50/60 Hz. The inrush power of this coil is 245 VA. It has an average sealed consumption of 27 VA. This coil has a height of 54.7 mm, a width of 81.5 mm and a depth of 48.3 mm. Coil is fully encapsulated to protect it. Coil has screw clamp connections. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
Schneider 3104140042 dimensions and weight
Dimensions (L × W × H)
Length
8.64 cm
Width
7.11 cm
Height
5.33 cm
Weight
Net Weight
0.5 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
