1SAM350000R1002 - MS132-0.25 Manual Motor Starter 0.16 ... 0.25 A | ABB
| Cat No. | 1SAM350000R1002 |
| Category | MPCB |
| Stock | In Stock |
| Condition | Brand New, Sealed Packaging |
| Product Type | MPCB |
In Stock — 15 Qty
$119.30
| Quantity | Expected Delivery |
|---|---|
| 15 Units | 25 Business Days |
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 23 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
ABB 1SAM350000R1002 MPCB Technical Specification
| MPCB | |
|---|---|
| Actuator Type | — |
| Application | Motor |
| Breaking Cap | - |
| OL Setting | — |
| Protection | Thermal Magnetic Release |
| Range of Product | — |
| Rating | 0.16-0.25A |
| Release | OverLoad, Short Circuit Protection |
| SC Setting | — |
| Type | MS132 |
Product Details
1SAM350000R1002 ABB MS132-0.25 - The MS132-0.25 manual motor starter (also known as motor protection circuit breaker or manual motor protector) is a compact 45 mm width device with a rated operational current of Ie = 0.25 A. This device is used to manually switch on and off motors and to protect them reliably and without the need for a fuse from short-circuits, overload and phase failures. The manual motor starter offers a rated service short-circuit breaking capacity Ics = 100 kA at 400 VAC and trip class 10. Further features are the build-in disconnect function, temperature compensation, trip-free mechanism and a rotary handle with a clear switch position indication. The manual motor starter is suitable for three- and single-phase applications. The handle is lockable to protect against unauthorized changes. Auxiliary contacts, signaling contacts, undervoltage releases, shunt trips, 3-phase bus bars, power in-feed blocks and terminal spacers are available as accessory. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
ABB 1SAM350000R1002 dimensions and weight
Dimensions (L × W × H)
Length
9.5 cm
Width
9.2 cm
Height
5 cm
Weight
Net Weight
0.5 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
1SAM350000R1002 ABB MS132-0.25 - The MS132-0.25 manual motor starter (also known as motor protection circuit breaker or manual motor protector) is a compact 45 mm width device with a rated operational current of Ie = 0.25 A. This device is used to manually switch on and off motors and to protect them reliably and without the need for a fuse from short-circuits, overload and phase failures. The manual motor starter offers a rated service short-circuit breaking capacity Ics = 100 kA at 400 VAC and trip class 10. Further features are the build-in disconnect function, temperature compensation, trip-free mechanism and a rotary handle with a clear switch position indication. The manual motor starter is suitable for three- and single-phase applications. The handle is lockable to protect against unauthorized changes. Auxiliary contacts, signaling contacts, undervoltage releases, shunt trips, 3-phase bus bars, power in-feed blocks and terminal spacers are available as accessory. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Frequently Asked Questions for 1SAM350000R1002
Electrihub is an authorized ABB distributor, guaranteeing 100% genuine ABB 1SAM350000R1002 or MS132-0.25 MPCB products backed by ABB warranty. With strong inventory and competitive pricing, we ensure quick delivery and reliable support for your automation needs.
Our experienced technical team is always ready to help you select the right ABB solution for your project — ensuring performance, safety, and peace of mind.
Our experienced technical team is always ready to help you select the right ABB solution for your project — ensuring performance, safety, and peace of mind.
The ABB 1SAM350000R1002 MPCB offers integrated overload, short circuit, and phase loss protection for motors. It combines protection and switching in one unit, supports adjustable thermal settings, and provides high-breaking capacity for industrial use.
It is used in MCC panels, pump stations, compressor motors, conveyor drives, HVAC motors and industrial automation circuits where reliable motor protection is essential.
It uses thermal magnetic mechanisms to detect overload, short circuit and phase imbalance. When detected, the breaker trips instantly to prevent winding damage and overheating.
Selection depends on full load current of the motor, service factor, starting characteristics and application duty. Set the adjustable dial to match motor nameplate current for proper protection.
Ensure correct line load connection, torque tightening of terminals, and coordination with ABB contactors when forming a starter. Provide ventilation and follow wiring diagrams.
Datasheet for 1SAM350000R1002 is available on Electrihub containing curves, wiring, and trip characteristics.
Yes. RAS Electrihub Private Limited provides PAN India delivery with reliable logistics, safe packaging, and doorstep delivery across all states and union territories.
Yes. RAS Electrihub Private Limited issues GST-compliant invoices and also supports PO-based invoicing for businesses, contractors, and organizations across India.
Yes. RAS Electrihub Private Limited operates as an ISO-certified organization, ensuring quality sourcing, authentic products, and standardized procurement and delivery processes.
The price of ABB 1SAM350000R1002 MPCB depends on specifications, availability, and market conditions. You can check the latest GST-inclusive price on Electrihub India, which provides genuine products, transparent billing, and PAN India delivery.
The ABB 1SAM350000R1002 is a high-performance MPCB (Motor Protection Circuit Breaker) designed to protect electric motors from thermal overloads, short-circuits, and phase failures. It combines the functionality of a thermal relay for overload protection and a magnetic circuit breaker for instantaneous short-circuit protection into a single compact device. You can source authentic ABB switchgear globally through Electrihub.
To calibrate the thermal trip setting on the ABB 1SAM350000R1002, locate the adjustable thermal release dial on the front facade of the unit. Use a precise calibration screwdriver to turn the dial until the pointer aligns with the Full Load Current (FLC) rating specified on your motor's nameplate. Proper coordination ensures optimal protection without nuisance tripping. For detailed wiring diagrams, check the Electrihub catalog.
The ABB 1SAM350000R1002 MPCB is fully modular and supports a wide range of clip-on accessories for automation. Compatible modules include HK1, SK1 auxiliary/signal contacts and UA1 releases. These allow for remote fault indication, shunt tripping, undervoltage safety interlocks, and seamless integration into PLC control panels. Explore the full accessory line on Electrihub.
The ABB 1SAM350000R1002 MPCB is engineered for standard industrial networks, typically rated up to 690V AC. Its ultimate short-circuit breaking capacity (Icu) depends on the specific voltage level (e.g., 400V/415V AC) and ranges from standard to high-fault capacities typical of the ABB MS116 / MS132 / MS165 Manual Motor Starters. Complete engineering parameters and datasheets are hosted on Electrihub.
Yes, the ABB 1SAM350000R1002 includes differential phase failure sensitivity in compliance with international standards like IEC/EN 60947-4-1. If a phase loss or severe unbalance occurs in the motor circuit, an internal slide mechanism accelerates the thermal trip response to prevent winding burnout. This critical safety feature is standard across all ABB MPCB models available at Electrihub.
