1SAM340000R1004 - MS132-0.63T Circuit Breaker for Primary Transformer Protection 0.40 ... 0.63 A | ABB
| Cat No. | 1SAM340000R1004 |
| Category | MPCB |
| Stock | Back Ordered |
| Condition | Brand New, Sealed Packaging |
| Product Type | MPCB |
Back Ordered
$125.41
Lead Time: 25 Working Days.
Reach out to us for project inquiries, Add to cart and click on send inquiry
Currently viewed by 32 usersSecure Payment with
Warranty Guarantee
100% Original Products
EEE Buyer Protection
World-Wide Reach
Technical Documents
No Data Available
There is no data to show you right now.
Technical Specification
ABB 1SAM340000R1004 MPCB Technical Specification
| MPCB | |
|---|---|
| Actuator Type | — |
| Application | Transformer |
| Breaking Cap | - |
| OL Setting | — |
| Protection | Thermal Magnetic Release |
| Range of Product | — |
| Rating | 0.40-0.63A |
| Release | OverLoad, Short Circuit Protection |
| SC Setting | — |
| Type | MS132 |
Product Details
1SAM340000R1004 ABB MS132-0.63T - The circuit breaker for transformer protection MS132-0.63T is a compact 45 mm width device designed to protect control transformers on the primary side. This device has a rated operational current of Ie = 0.63 A. It allows fuse-less protection against overload and short-circuit. The short-circuit current setting is fixed to 20 times the rated operational current to handle the high inrush current generated by transformers. The device allows manually connect and disconnect the transformer from the mains thanks of its built-in disconnection function. The circuit breaker for transformer protection offers a rated service short-circuit breaking capacity of Ics = 100 kA at 400 VAC and a trip class 10. Further features are temperature compensation, trip-free mechanism, rotary handle with a clear switch position indication and short circuit trip indicator. The handle is lockable to protect against unauthorized changes. Auxiliary contacts, signalling contacts, undervoltage releases, shunt trips, power in-feed blocks and terminal spacers are available as accessory. We are dedicatedly involved in providing an excellent quality products at Electrihub.
Product Dimensions
ABB 1SAM340000R1004 dimensions and weight
Dimensions (L × W × H)
Length
9.5 cm
Width
9.2 cm
Height
5 cm
Weight
Net Weight
0.5 kg
Dimensions are approximate. For precise dimensional drawings, contact us.
Related Products
Frequently Bought Together
Product Line Card
No Data Available
There is no data to show you right now.
Alternate Products
Product Overview
1SAM340000R1004 ABB MS132-0.63T - The circuit breaker for transformer protection MS132-0.63T is a compact 45 mm width device designed to protect control transformers on the primary side. This device has a rated operational current of Ie = 0.63 A. It allows fuse-less protection against overload and short-circuit. The short-circuit current setting is fixed to 20 times the rated operational current to handle the high inrush current generated by transformers. The device allows manually connect and disconnect the transformer from the mains thanks of its built-in disconnection function. The circuit breaker for transformer protection offers a rated service short-circuit breaking capacity of Ics = 100 kA at 400 VAC and a trip class 10. Further features are temperature compensation, trip-free mechanism, rotary handle with a clear switch position indication and short circuit trip indicator. The handle is lockable to protect against unauthorized changes. Auxiliary contacts, signalling contacts, undervoltage releases, shunt trips, power in-feed blocks and terminal spacers are available as accessory. We are dedicatedly involved in providing an excellent quality products at Electrihub.
